Dimensions
5.6 in. L x 2.6 in. W x 1.0 in. D 14

.2 cm L x 6.6 cm Wx 2.5 cm D

Weight : 8.73 oz./247.4 g

Display : Outdoor-viewable 3.2 in. QVGA with backlight, 240 W x 320 L

Touchpanel : Polycarbonate analog resistive touch

Backlight : LED backlight

Standard Battery : Rechargeable Lithium Ion 3.7V, 3080 mAh

Expansion Slot : User accessible 32 GB microSD slot with SDHC support

Network Connections : USB 2.0 High Speed (host and client), WLAN, WWAN and Bluetooth

Notification : Vibrator and audible tone plus multi-color LED

Keypad : 26-key numeric

Voice and Audio VoWWAN: handset mode with active noise reduction, hi ghfquality speaker phone, Bluetooth wireless headset mode

PERFORMANCE CHARACTERISTICS

CPU : 600 MHz, ARM 11 processor, MSM 7627

Operating System :
Microsoft@ Windows Embedded

HandheldTM 6.5.3 Professional Edition

Memory : 256 MB RAM /1GB Flash

USER ENVIRONMENT

Operating Temp. : -10C to 50C/14'F to 122'F

Storage Temp. :-40C to 70'C 1-40'F to 158'F

Humidity :5% to 95% non-condensing

Drop Specification : Multiple 6 ft./1.8 m drops per MIL-STD-810G

Tumble Specification : 250 0.5 m (1.5 ft.) tumbles (500 drops); per applicable IEC tumble specifications

ESD : +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge

Sealing : IP 64 per applicable IE C sealing specifications

Vibration :
.02g2/Hz Random, Non-Operating, 1 hour
duration per axis

Thermal Shock
-40'F to 158 F1-40~C to 70~C rapid transition

ZEBRA INTERACTIVE SENSOR TECHNOLOGY (IST)

Ambient Sensor : Light Automatically adjusts required display backlight to maximize power efficiency

Proximity sensor : Automatically detects when the user places the handset against head during a phone call to disable display output and touch input

Camera : Autofocus 3.2 MP with user-controllable flash; supports integrated 1D/2D bar code capture

1-D Laser Scanner : 1-D* Iaser with Adaptive Scan technology

* Please refer to the MC45 User Guide or Integrator Guide for full data capture specifications.

WIRELESS WAN DATA AND VOICE COMMUNICATIONS

Radio : 3.5G HSDPA, Quad-Band GPRS/EDGE

Frequency Band : GSM - Quad Band : 850/900/1800/1900 MHz UMTS/HSDPA - Americas: 850/ 1900 MHz UM TS/HSDPA - Rest of the world: 210 0 MHz

GPS : Integrated, Autonomous and Assisted-GPS (A-GPS)

WIRELESS LAN DATA AND VOICE COMMUNICATIONS

Radio : Tri-mode IEEE @ 802.11a/b/g

Data Rates Supported : 1, 2,5.5, 6, 9, 11, 12, 18, 24, 36,48, and 54 Mbps

Security : WPA2, WEP (40 or 128 bit), TKIP,TLS, TTLS MSCHAP),TTLS (MS-CHAP v2), TTLS (CHAP), TTLSMD5,TTLS-PAP, PEAP-TLS, PEAP (MS-CHAP v2),AES, LEAP, CCXv4 certified

WIRELESS PAN DATA AND VOICE COMMUNICATIONS

Bluetooth Class II , V2.0 with Enhanced Data Rate (EDR)
