Physical Characteristics Zebra Mobile Computer TC20

Dimensions
TC20 ALL-TOUCH:
5.27 in. L x 2.82 in. W x .63 in. D
134 mm L x 73.1 mm W x 16 mm D
TC20 WITH KEYBOARD:
6.45 in. L x 2.82 in W x .63 in. D
164 mm L x 73.1 mm W x 16 mm D

 Weight
TC20 ALL-TOUCH: 6.88 oz./195 g
TC20 WITH KEYBOARD: 7.58 oz./215 g

Display  :  4.3 in. color WVGA (800x480); LED backlight; Corning Gorilla Glass
Imager Window  : Corning Gorilla Glass
Touch Panel  :   Capacitive Touch Panel; multi-touch
Power  :  Non-removable    Rechargeable Li-Ion: standard capacity, 3000mAh  Charge in under 4 hours (10hrs = 1 Shift)  RTC backup
Expansion Shot :  One 128GB micro SD slot
Network Connections   : One USB OTG - host/client  (Type C connector)
Notifications   :   Unsolicited packet data and programmable
Keypad
TC20 All-Touch: On-screen Keypad
TC20 Keyboard: Numeric
Voice  :   PTT Pro, PTT Express
Audio  :  Speaker - 1 Watt (94dBA)  Voice support (Internal speaker/microphone)  2 microphones  Audio jack
Buttons                Scan on each side, Volume Up/Down, Power, push-to-talk (PTT) Key

Performance Characteristics
CPU       QCOM MSM8937® 64-bit 8-Core, ARM® Cortex A53 1.4GHz, 512KB L2 cache, power-optimization
Operation System          Android Oreo 8.1
Memory             2GB RAM/16 GB Flash memory
Security                 Verified Boot

Operating Temperature    14° F to 122° F / -10° C to 50° C
Storage Temperature    -40° F to 158° F / -40° C to 70° C
Drop Specifications        Multiple 4 ft./1.2 m drop to tile over concrete per MIL-STD at room temperature
Tumble Specifications   300 tumbles, 1.6 ft./0.5m
Sealing                IP65
Vibration            4G peak, 5 Hz to 2 kHz, 1 hour duration per axis
Thermal Shock    -40°C to 70°C rapid transition   10 cycles (1 cycle = 1.25 hours at -40°C and 1.25 hours at 70°C)
Electrostatic Discharge (ESD)   +/-15kv Air, +/-8kv contact, +/-8kv charge body

Interactive Sensor Technology (IST)
Accelerometer (3-axis), ambient light sensor, proximity sensor

Data Capture

Scanning
SE2100 1D/2D imager
SE4710 1D/2D imager + rear camera

Rear Camera     8MP autofocus color camera with flash

RFID      RFD2000 UHF RFID snap-on sled

Wireless LAN

WLAN Radio      802.11 a/b/g/n/ac/d/r/h/i IPv4, IPv6
Data Rates
2.4 GHz: 20 MHz, 40 MHz
5 GHz: 20 MHz, 40 MHz, 80 MHz
Operating Channels
2.4 GHz (channels 1-13; 1-11(US))
5GHz (channels 36-48, 52-64, 100-144, 149-165)
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.
Security and Encryption
WPA/WPA2 (PSK & Enterprise 802.1x); EAPTTLS; PEAPv0-MSCHAPv2; EAP-TL
Certifications    802.11a/b/g/n; WPA; WPA2
Fast Roam          802.11r

Wireless PAN
Bluetooth          Bluetooth 4.2 BLE
