Physical Characteristics Zebra Mobile Computer MC67

Dimensions
6.38 in. L x 3.03 in. W x 1.32 in. D
162.2 mm L x 77 mm W x 33.5 mm D
Weight  : 13.5 oz./385 g (with battery)
Display  : 3.5 in. color VGA display, touch, 640 x 480 portrait
Touchpanel :  Glass analog resistive touch
Backlight  :  LED backlight
Power  : PowerPrecision 3600 mAh Li-Ion  rechargeable battery
Backup Battery  :  Ni-MH battery (rechargeable) 15 mAh 3.6V nominal (not user-accessible or replaceable)
Expansion Slot  :  Micro SD card slot (supports up to 32 GB)
Communication  :  Interface: USB 2.0 high speed (host and client)
Notification  : Audible tone plus multi-color LEDs

Keypad Options  :
Premium WEHH models: QWERTY, Numeric, AZERTY,QWERTZ, PIM, DSD
Premium Android 4.1 models: QWERTY, Numeric, AZERTY, QWERTZ, DSD
Premium Android 4.4 models: QWERTY, Numeric, DSD
Base WEHH models: QWERTY, Numeric, Calc DSD
Audio Dual microphone support with noise cancellation;vibrate alert; speaker; Bluetooth headset

Performance Characteristics

CPU
Premium models: Dual core 1 GHz OMAP 4 processor
Base models: Dual core 800 MHz OMAP 4 processor
Operating System Android Jelly Bean 4.1 or Android KitKat 4.4  with Mobility Extensions (Mx); Windows  Embedded Handheld 6.5 Professional
Memory
Premium WEHH models: 512 MB RAM/2 GB Flash or 1 GB RAM/8 GB Flash
Premium Android models: 1 GB RAM/8 GB Flash
Base WEHH models: 512 MB RAM/2 GB Flash

User Environment

Operating Temp. -4° F to 122° F/-20° C to 50° C
Storage Temp. -40° F to 158° F/-40° C to 70° C
Humidity 5 to 95% non-condensing

Drop Specification
Premium models: Multiple 8 ft./2.4 m drops per MILSTD 810G at room temperature; 6 ft./1.8 m per MIL-STD 810G across the operating temperature range
Base models: Multiple 6 ft. drops per MIL-STD 810G
Tumble Specification
2,000 1.6 ft./0.5 meter tumbles; meets and exceeds IEC tumble specifications
Sealing
Premium models: IP65 and IP67 per IEC specification
Base models: IP64
Vibration 4g’s PK Sine (5Hz to 2KHz); 0.04g2/Hz Random (20Hz to 2KHz); 60 minute duration per axis, 3 axes
Thermal Shock -40° F to 158° F/-40° C to 70° C rapid transition
ESD
± 15kv Air discharge,
± 8kv direct discharge,
± 8kv indirect discharg

VOICE AND AUDIO
High-quality speakerphone; Bluetooth headset; handset/speakerphone modes

INTERACTIVE SENSOR TE CHNOLO GY (IST )
Motion Sensor 3-axis accelerometer senses motion for dynamic screen orientation and power management
Light Sensor Ambient light sensor auto adjusts display backlight brightness
Digital Compass Navigational aid for users on foot

DATA CAPTURE

Options
Premium Android models:  2D SE4500-SR imager + 8 MP Camera
Premium WEHH models:
2D SE4500-SR imager + 8 MP Camera;
2D SE4500-SR imager; 2D SE4500-DL imager
+ 8 MP Camera; 2D SE4500-DL imager;
2D SE4500-DPM/HD + 8 MP Camera
Base WEHH models:
2D SE4710 imager + 8 MP Camera; 2D SE4710 imager
Data Types 1D/2D barcodes, photographs, video, signatures and documents (Only WEHH supports document capture)

WIRELESS VOICE AND DATA COMMUICATIONS

WWAN Radio: 4G HSPA+; Frequency band: UMTS/HSDPA and HSUPA — 850, 900, 1900 and 2100 MHz; GSM/ EDGE: 850, 900, 1800 and 1900 MHz
WLAN Push-to-Talk (PTT) ready

WIRELESS LAN VOICE AND DATA COMMUICATIONS

Radio Tri-mode IEEE® 802.11a/b/g/n
Security WPA2 (Personal or Enterprise); 802.1x; EAP-TLS;TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5);PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP, EAP-FAST (TLS, MS-CHAPv2, EAP-GTC), CCX v4
Data Rates 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 and up to 72.2 Mbps
Voice Communication
Wi-Fi™-certified, IEEE 802.11a/b/g/n direct sequencewireless LAN, Wi-Fi Multimedia™ (WMM and WMMPS) Zebra Voice Quality Manager (VQM)

INTEGRATED GPS

Integrated standalone and Assisted-GPS (A-GPS): SUPL 1.0

WIRELESS PAN VOTCE AND DATA COMMUNICATIONS

Bluetooth Class II, v2.1 with Enhanced Data Rate (EDR)
