Physical Characteristics Zebra Mobile Computer TC21 TC26

Dimensions
With standard battery:
6.22 in. L x 3.11 in. W x .0.54 in. D
158 mm L x 79 mm W x 13.7 mm D
With extended battery:
6.22 in. L x 3.11 in. W x .0.68 in. D
158 mm L x 79 mm W x 17.3 mm D
Weight                8.32 oz./236 g with standard battery; 269 g with extended battery
Display   5.0 in. color HD (1280 x 720); LED backlight; Corning® Gorilla® Glass
Imager Window  Corning® Gorilla® Glass
Touch Panel      Capacitive Touch Panel; multi-touch
Power
Removable/serviceable rechargeable Li-Ion
Standard Capacity 3300 mAh
Enhanced Capacity 5400 mAh
Expansion Slot  One 128 GB micro SD slot
SIM       1 Nano SIM slot; optional eSIM (TC26 only)
Network Connections   1 USB 2.0 OTG - host/client; Type C connector
Notifications     Audible tone; multi-color LEDs; vibration
Keypad   On-screen keypad
Audio
Speaker - 1 Watt
Voice support (Internal speaker/receiver and microphones)
Buttons  Scan on each side; volume up/down; power; push-to-talk (PTT) keys

Performance Characteristics

CPU       Qualcomm SnapdragonTM 660 octa-core, 1.8 GHz
Operating System     Android 10 with built in support for a future  Android release
Memory             4 GB RAM/64 GB Flash memory; 3 GB RAM/32 GB Flash memory; 2 GB RAM/16 GB Flash memory (not available in all markets)

User Environment

Operating Temp.            14°F to 122°F / -10°C to 50°C
Storage Temp.                 -30°F to 158°F / -30°C to 70°C
Humidity            5% - 95% non condensing
Drop Spec.         4 ft./1.2 m drop to concrete per MIL-STD 810G across operating temperature
Tumble Spec.    300 tumbles, 1.6 ft./0.5 m
Sealing  IP67
Electrostatic Discharge (ESD)     +/-15 kV air discharge, +/-8 kV direct discharge; +/-8 kV indirect discharge

Interactive Sensor Technology (IST)

Light Sensor       Automatically adjusts display backlight brightness
Motion Sensor  3-axis accelerometer with MEMS Gyro
Proximity Sensor     Automatically detects when the user places the handset against head during a phone call to disable display output and touch input.

Data Capture

Scanning
SE4100 1D/2D imager
SE4710 1D/2D imager
Camera scanning (SKU dependent)
Camera   Rear camera 13 MP; optional front camera 5 MP
NFC       Integrated; MIFARE, ISO 14443 A&B , FeliCa , ISO 15693 and NFC Forum supported cards; read range up to 50 mm

Wireless WAN Data and Voice Communications

Radio Frequency Band (TC26 only)
TC26 North America
UMTS: B2/B4/B5
LTE: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B66
LTE: Category 6
TC26 Rest of World
GSM: 850/900/1800/1900
UMTS: B1/B2/B3/B4/B5/B8/B9/B19
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B19/B20/B28
LTE-TDD: B38/B40/B41
LTE: Category 6
TC26 China
GSM: 850/900/1800
UMTS: B1/B5/B8
LTE-FDD: B1/B3/B5/B7/B8
LTE - TDD: B38/B39/B40/B41
LTE: Category 6

Voice Communications
Optional Push-to-Talk (PTT) Express¹ Mobility DNA software application for instant PTT walkie-talkie style calls inside the four walls.

Optional Workforce Connect Push-to-Talk (PTT) Pro² Mobility DNA easy-to-deploy, cost-effective subscription-based software application that provides instant PTT walkie-talkie style calls inside and outside the four walls via an easy-to-deploy subscription service.

Optional Workforce Connect Voice³ to turn TC21/TC26 devices into fully-featured PBX handsets with a custom interface that makes it easy to execute even the most complex telephony features — eliminating the need to purchase and manage additional voice-enabled devices.

GPS (TC26 only)              GPS with A-GPS: Glonass; BeiDou; Galileo

Wireless LAN

WLAN Radio      IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w; Wi-Fi™ certified; IPv4, IPv6, 1x1 MU-MIMO
Data Rates
2.4 GHz: 802.11b/g/n — 20MHz, 40MHz — up to 150 Mbps
5 GHz: 802.11a/g/n/ac – 20MHz, 40MHz, 80MHz – up to 433 Mbps
Operating Channels
Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
Channel 36-165 (5180-5825MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency
Security and Encryption              WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA3⁴ Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3⁴ Enterprise (AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and EAP-PWD; WPA Enterprise 192-bit Mode (GCMP-256) - EAP-TLS; Enhanced Open (OWE)
Certifications    802.11a/b/g/n; WPA; WPA2; WPA3⁴
Fast Roam          PMKID caching; Cisco CCKM; 802.11r (Over-The-Air); OKC

Wireless PAN

Bluetooth          Bluetooth 5.0 BLE, Class 2
