PHYSICAL CHARACTERISTICS Zebra Mobile Computer MC18

Dimensions
2.95 in. H x 8.58 in. L x 3.09 in. W
7.50 cm Hx 21.80 cm Lx 7.86 cm W
Weight 10.6 oz./300 g (with battery)
Display : Color LCD; 4.0 inch 480 x800 WVGA resolution; with Tianma display, 24 bits/pixel RGB; LED backlight; capacitive touch screen; Corning Gorilla Glass 3
Keyboard : 1dedicated scan button
Power Source :PowerPrecision+ 2725 mAh Li-lon rechargeable battery
Processor : TI OMAP4430, Dual Core ,1GHz
Operating System   :
Android 5.1 (Lollipop)
Windows Embedded Compact 7 (Microsoft Internet Explorer Embedded 7)
Memory
Android configurations: 1GB RAM/4 GB Flash
Windows Embedded Compact 7 Configurations: 1GB RAM/4 GB Flash
Interface/Communications :
USB 2.0 Client for Microsoft ActiveSync for service and maintenance
Light Source : Red LED Illumination with LED dot aim pattern
Scan Rate : Imaging rate: 30 Frames per second, 1280p x800p
Ambient Light Immunity :
Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions.
Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED: 450 Ft. Candles (4,844 Lux)
Sunlight: 8,000 Ft. Candles (86,111 Lux)

WIRELESS NETWORKING

WLAN : 802.11a/b/g/n/d/h/i/k/r (802.11 k/r - Android only)
WPAN :
Bluetooth Class 1.5 2.1+EDR
Bluetooth 4.0 with Bluetooth SMART technology

WIRELESS SECURITY

Security and Encryption  :
WEP (40 or 104 bit) ;WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP, and AES)-EAP-TTLS (PAP, MSCHAP, MSCHAPV2), EAP-TLS,PEAPVO-MSCHAPV2, PEAPV1-EAP-GTC, EAP-FAST (MSCHAPV2 and EAP-GTC) and LEAP

USER ENVIRONMENT

Operating Temperature : 32~ to 104 F/0~to 40 C
Storage Temperature : 4~ to 140~F/-20~ to 60~ C
Humidity : 40 C (RH 10% - 95%) non-condensing
Drop Specification : Withstands multiple 4 ft./1.2 m drops to vinyl tile over concrete
Tumble Specification : 1,000 0.5 m/1.64 ft. tumbles at room temperature

REGULATORY

Electrical Safety : Certified to UL/cUL 60950-1, EN/IEC 60950-1; IEC 62471:2006/EN62471:2008(LED  Safety Report)
EMI/RFI :
North America: FCC Part 15 Subpart B Class B
Canada: ICES 003 Class B
EU: EN55022 Class B, EN 301 489-1, EN 301 489-17, EN61000-4-3/-3-21-3-3, EN 55024
Environmental : ROHS compliant -2011/65/EEC, WEEE -2002/96/EC
