PHYSICAL CHARACTERISTICS Mobile Computer MC40
Dimensions With Magnetic Stripe Reader (MSR):
5.66 in. H x 2.87 in. W x 1.25 in. D
143.9 mm H x 72.8 mm W x 31.8 mm D
Without Magnetic Stripe Reader:
5.66 in. H x 2.87 in. W x 0.79 in. D
143.91 mm H x 72.8 mm W x 20.1 mm D
Weight with Battery
With MSR: 9.38 oz./266.1 g
Without MSR: 9.09 oz./257.7 g
Display 4.3 in. capacitive; 480 x 800; 450 NITS
Touchpanel Capacitive dual-touch; Corning Gorilla Glass
Backlight LED backlight
Power PowerPrecision 2680 mAh Li-Ion rechargeable battery
Backup Battery1 NiMH battery (rechargeable) 15 mAh 3.6 V
(not user accessible)
Connectivity USB 2.0 OTG connector
Notification LED, audio and vibration
Keypad On-screen keypad
Disinfectant Ready Yes (Healthcare version)
Colors Silver, Healthcare Blue and White
PERFORMANCE CHARACTERISTICS
CPU 1 GHz OMAP 4 dual core processor
OS Android 5.1 Lollipop with Zebra’s , Mobility Extensions (Mx)
Memory 1 GB RAM/8 GB pSLC Flash
USER ENVIRONMENT
Operating Temp. 0° C to 40° C / 32° F to 104° F
Storage Temp. -40° C to 70° C / -40° F to 158° F
Humidity 5% to 85% RH non-condensing
Drop Specification
Multiple 4 ft./1.2 m drops per MIL-STD 810G;
multiple 3 ft./0.9 m drops to tile
Tumble Specification
500 1.6 ft/0.5 m tumbles; meets and exceeds IEC tumble specifications
Sealing IP54
ESD
± 15kVdc air discharge,
± 8kVdc direct discharge,
± 2kVdc indirect discharge
Corning Gorilla Glass
Touchpanel; scanner exit window; camera exit window
AUDIO
High-quality speakerphone, wireless (Bluetooth) headset
support, PTT headset support, handset/speakerphone modes
INTERACTIVE SENSOR TECHNOLOGY (IST)
Motion Sensor 3-axis accelerometer provides motionsensing
for dynamic screen orientation and power management
|
INTERACTIVE SENSOR TECHNOLOGY (CONTINUED)
Light Sensor Automatically adjusts display backlight brightness
Proximity Sensor Prevents unwanted key presses in handset mode
DATA CAPTURE
Imager SE4710
Camera Rear-facing 8 MP auto-focus with aiming for barcode scanning and image capture
Payment Transactions
Integrated Magnetic Stripe Reader (MSR)
with encrypted head (optional)
Data Types 1D/2D barcodes, photographs, video, signatures, documents; credit, loyalty and gift cards as part of a payment transaction (MSR model only)
COMMUNICATION AND MESSAGING
Workforce Connect PTT Express Client included for instant PTT calling right out of the box. Workforce Connect Voice Client Certified to enable PBX handset functionality and more inside the four walls. Supports Workforce Connect PTT Pro for more robust PTT functionality and Workforce Connect Messaging for text messaging over Wi-Fi and cellular networks. 2, 3
WIRELESS LAN
Radio Tri-mode IEEE® 802.11a/b/g/n/d/h/i/k/r4
Security
Security Modes: Legacy, WPA and WPA2
Encryption: WEP (40 and 128 bit), TKIP and AES
Authentication: TLS, TTLS (MS-CHAP), TTLS (MS-CHAP v2), TTLS (PAP), PEAP (MS-CHAP v2), PEAP (GTC), FAST (MS-CHAP v2), FAST (GTC), LEAP.
Data in Motion: FIPS 140-2 Level 1
Data at Rest: FIPS 140-2 Level 1
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5, 13, 19.5, 26, 39, 52, 58.5,65 Mbps
802.11n with SGI: 7.2, 14.4, 21.7, 28.9, 43.3,57.8, 65, 72.2 Mbps
Fast Roam PMKID Caching, Opportunistic Key
Caching (OKC), Cisco CCKM, 802.11r,Zebra Aggregated FT5
Certifications Wi-Fi, CCXv4
Operating Channels
Chan 36-165 (5180 – 5825 MHz), Chan 1-13 (2412 - 2472 MHz); actual operating channels/frequencies depend on regulatory rules and certification agency
WIRELESS PAN
Bluetooth Class II, v 2.1 with EDR; Bluetooth 4.0 (Bluetooth Smart)
|
