Physical Characteristics  Mobile Computer Zebra TC52 TC57

Dimensions
6.1 in. L x 2.9 in. W x 0.73 in.
155 mm L x 75.5 mm W x 18.6 mm H
Weight   8.8 oz./249 g with battery
Display   5.0 in. High Definition (1280 x 720); exceptionally bright, outdoor viewable; optically bonded to touch panel
Imager Window    Corning Gorilla Glass
Touchpanel       Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately); Corning Gorilla Glass; water droplet rejection; fingerprint resistant anti-smudge coating
Backlight   LED backlight
Power   Rechargeable Li-Ion, PowerPrecision+, > 15.48 Watt hours, > 4150 mAh, improved battery metrics for better battery management, fast charging (up to 2.4 A)
Expansion Slot  User accessible MicroSD up to 32GB SDHC and up to 256 GB SDXC
SIM Slots   TC57 only: 1 nano SIM
Network Connections    TC52/TC57: WLAN, WPAN (Bluetooth), USB 2.0, High
Speed (Host and Client)
TC57 Only: WWAN
Notification        Audible tone; multi-color LEDs; vibration
Keypad    On-screen keypad and enterprise keyboard
Voice and Audio   Three microphones with noise cancellation; vibrate alert; Front facing speaker; Bluetooth wireless headset support; High quality speaker phone; PTT headset support; cellular circuit switch voice; HD Voice; and SWB & FB audio
Buttons  Six programmable buttons for maximum flexibility: Back button, dual dedicated scan buttons, dedicated push-to-talk button and volume up/down buttons

Performance Characteristics

CPU       Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System
TC52: Android 10; upgradeable through A11/R3
TC57: Android 10; upgradeable through A11/R3
Both with Zebra’s Restricted Mode for control over GMS and other services.
Memory             4GB RAM/32GB Flash

User Environment

Operating Temp.  : -4°F to 122°F/-20°C to 50°C
Storage Temp.  :   -40°F to 158°F/-40°C to 70°C
Humidity  : 5% to 95% non-condensing
Drop Specifications  :  Multiple 6 ft. drops to concrete with the rugged boot accessory per Mil STD 810 G; Multiple 4 ft/1.2m drops to tile over concrete -10°C to 50°C (14°F to 122°F)
Tumble Specification   :  500 1.6 ft./0.5 m tumbles, meets or exceeds IEC tumble specification
Sealing   :  IP68 and IP65 per applicable IEC sealing specifications
Vibration  :   4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock   :   -40° F to 158° F/-40° C to 70° C rapid transition

Electrostatic

Discharge (ESD)    :
+/- 15kv air discharge;
+/- 8kv direct discharge;
+/- 8kv indirect discharge

Interactive Sensor Technology (IST)
Light Sensor       Automatically adjusts display backlight brightness
Magnetometere   Compass automatically detects direction and orientation
Motion Sensor  3-axis Accelerometer with MEMS Gyro
Pressure Sensor   Automatically detects altitude information for locating (TC57 only)
Proximity Sensor     Automatically detects when the user places the handset against head during a phone call to disable display output and touch input

Data Capture

Scanning   :  SE4710 imager (1D and 2D) with extraordinary range:
Scan range  :   – Code 39 barcode:
    20 Mil: 2.0 in. to 30.0 in./5.08 cm to 76.2 cm
    4 Mil: 3.3 in. to 8.8 in./8.4 cm to 22.4 cm
Digimarc support
Camera
Front — 5 MP; f/2.0 aperture
Rear — 13 MP autofocus; f/2.2 aperture; flash LED generates balanced white light; supports Torch mode
NFC       ISO 14443 Type A and B; FeliCa and ISO 15693 cards; P2P mode and Card Emulation via Host.
TC57 Only: Card Emulation via Host and UICC

Wireless WAN Data and Voice Communications (TC57 Only)
Radio Frequency Band  Supports VoLTE , Carrier Aggregation up to 3DL CA
AT&T FirstNet Ready certification
Verizon PNTM certification
LTE FDD: 700/800/850/900/1800/1900/AWS/2100/2600  (28,13,14,12,17/19,20/5,26/8/3/2,25/4,66/1/7);
LTE TDD: 1900/2300/2500 (39/40/41,38);
UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100 (5/8/4/2/1);
GSM/GPRS/EDGE: 850/900/1800/1900
GPS       TC57 only: Autonomous, Concurrent GPS; GLONASS; Gallileo; BeiDou, and A-GPS.  Supports IZAT™ XTRA
Multimedia  Wi-Fi Multimedia™ (WMM) and WMM-PS; Including TSPEC

Wireless LAN

Radio
TC52: IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w; Wi-Fi™ certified; IPv4, IPv6, 2x2 MU-MIMO
TC57: IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w; Wi-Fi™ certified; IPv4, IPv6, 5GHz 2x2 MU-MIMO
Data Rates
5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps
Operating Channels
Channel 1-13 (2412-2472 MHz): 1,2,3,4,5,6,7,8,9,10,11,12,13
Channel 36-165 (5180-5825 MHz): 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,136,140,144,149,153,157,161,165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.
Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP.EAP-PWD
Certifications     WFA (802.11n, WMM-PS, 801.11ac, PMF)
Fast Roam          PMKID caching; Cisco CCKM; 802.11r; OKC

Wireless PAN

Bluetooth   Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE)
