Physical Characteristics  Mobile Computer TC70

Dimensions
6.3 in. L x 3.3 in. W x 1.1 in. D
161 mm L x 84 mm W x 28 mm D
Weight  13.3 oz./376 g
Display  4.7 in. High Definition (1280 x 720); exceptionally bright, outdoor viewable; optically bonded to touch panel
Imager Window  Corning Gorilla Glass
Touch Panel    Dual mode capacitive touch with stylus, finger or gloved fingertip input (conductive stylus sold separately); Corning Gorilla Glass
Backlight    LED backlight
Power   Li-Ion 3.7 V, 4620 mAh. PowerPrecision/PowerPrecision+1: Improved battery technology for longer cycle times and real-time visibility into battery metrics for better battery management.
Expansion Slot
TC70: User accessible MicroSD with 32GB SDHC and up to 64GB SDXC
TC70x: User accessible MicroSD with 32GB SDHC and up to 128GB SDXC
Network Connections   WLAN, WPAN (Bluetooth)
Notification   Audible tone; multi-color LEDs; vibration
Keypad On-screen keypad; Enterprise Keyboard
Voice and Audio  Three microphone support with noise cancellation; vibrate alert; speaker; Bluetooth wireless headset support

Performance Characteristics

CPU
TC70: 1.7 GHz dual core processor
TC70x: 1.8 GHz hexa-core 64 bit processor
Operating System
TC70: Android 5 Lollipop
TC70x: Android 8.1 (Oreo)
Memory
TC70: 1 GB RAM / 8 GB Flash pSLC
TC70x: 2 GB RAM / 16 GB Flash pSLC or 4 GB RAM / 32 GB Flash pSLC

User Environment

Operating Temperature  -4° F to 122° F/-20° C to 50° C
Storage Temperature    -40° F to 158° F/-40° C to 70° C
Humidity    5% to 85% non-condensing
Drop Specification     Multiple 6 ft./1.8 m drop to concrete across full operating temperature range, multiple 8 ft./2.4 m drop to concrete at room temperature per MIL-STD 810G
Tumble Specificiation    2,000 3.2 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Sealing  IP65 and IP67 per applicable IEC sealing specifiications
Vibration  :  4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock
-40° F to 158° F/-40° C to 70° C rapid transition
Electrostatic Discharge (ESD)
+/-15kVdc air discharge
+/-8kVdc direct discharge
+/-8kVdc indirect discharge
Audio
High quality speaker phone with up to 108 dB SPL volume; wireless (Bluetooth) headset support; PTT headset support; handset/speakerphone modes
Interactive Sensor Technology (IST)
Light Sensor       Automatically adjusts display backlight brightness
Motion Sensor  3-axis accelerometer for dynamic screen orientation

Data Capture

Scanning
SE4750 imager (1D and 2D); extraordinary range:Scan range
– Code 39 barcode:20 Mil: 1.6 in to 36.3 in/4.1 cm to 92.2 cm,  3 Mil: 2.8 in to 6.2 in/7.1 cm to 15.8 cm
Camera
TC70:  Front-1.3 MP fixed focus,  Rear - 8 MP autofocus
TC70x: Front-1.3 MP fixed focus, Rear - 13 MP autofocus
NFC       ISO 14443 Type A and B; FeliCa3, and ISO 15693 cards. P2P mode and Card Emulation via UICC and Host

Wireless LAN

Radio
TC70: IEEE 802.11a/b/g/n/d/h/i/k/r
TC70x: IEEE 802.11a/b/g/n/ac/d/h/i/k/r/w
Data Rates
TC70
5GHz: 802.11a/n — up to 150 Mbps;
2.4GHz: 802.11b/g/n — up to 72.2 Mbps
TC70x
5GHz: 802.11a/n/ac — up to 866.7 Mbps;
2.4GHz: 802.11b/g/n — up to 144.4 Mbps
Operating Channels
TC70: Chan 1 - 13 (2412 - 2472 MHz); Chan 36 - 165 (5180 - 5825 MHz); Channel Bandwidth: 20, 40 MHz
TC70x: Chan 1 - 13 (2412 - 2472 MHz), Chan 36 - 165 (5180 - 5825 MHz); Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies depend on regulatory rules and certification agency
Security and Encryption
TC70:  WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP, and AES) — EAPTTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PE APv0-MSCHAPv2, PE APv1-EAP-GTC, EAP Fast and LEAP
TC70x: WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP, and AES) — EAP TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP
Data in Motion: FIPS 140-2 Level 1
Data at Rest: FIPS 140-2 Level 1
Multimedia        TC70/TC70x Android: Wi-Fi Multimedia™ (WMM) and WMM-PS
Certifications
TC70: WFA (802.11n, WMM, WMM-PS, Wi-Fi Direct, Miracast, Soft-AP, WPS 2.0) and Cisco CCXv4
TC70x Android: (802.11n, 802.11ac, WMM-PS, WMM-AC, Voice Enterprise, Miracast)
Fast Roam          TC70/TC70X Android: PMKID caching, Opportunistic Key Caching (OKC), Cisco CCKM and FT (802.11r)

Wireless PAN
Bluetooth          Class 2, Bluetooth v4.0 (Bluetooth® Smart technology) BT Wideband support HFPv1.6 ,  Bluetooth v4.1 LE (TC70x only)
Communication and Messaging
Workforce Connect PTT Express (included) provides instant push-to-talk small group communications across Wi-Fi networks. Workforce Connect PTT Pro (supported) provides a scalable network agnostic push-to-talk solution which also includes messaging, location services and two-way radio integration. Workforce Connect Voice client (supported) enables the TC70 Series to function as a full featured mobile telephone with multi line  capability across Wi-Fi networks.
