คุณสมบัติอย่างย่อ Mobile computer Zebra TC72

ระบบการอ่าน : 1D , 2D

หน่วยประมวลผล :  Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz

หน่วยความจำ :  4 GB RAM/32 GB Flash pSLC

หน้าจอ :  4.7 in. High Definition (1280 x 720)

รองรับการเชื่อมต่อ : WLAN, WPAN (Bluetooth)

ระบบปฏิบัติการ :  Android 10; upgradeable through A11/ R22

กันกระแทก : Multiple 6 ft./1.8 m drop to concrete across full operating temperature range, multiple 8 ft. / 2.4 m drop to concrete at room temperature per MIL-STD 810G

คุณสมบัติอย่างย่อ Mobile computer Zebra TC77

 ระบบการอ่าน : 1D , 2D

หน่วยประมวลผล :  Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz

หน่วยความจำ :  4 GB RAM/32 GB Flash pSLC

หน้าจอ :  4.7 in. High Definition (1280 x 720)

รองรับการเชื่อมต่อ : WWAN (cellular, WLAN (WiFi), WPAN (Bluetooth); USB 2.0 High Speed (host and client) ,SIM

ระบบปฏิบัติการ :  Android 10; upgradeable through A11/ R22

กันกระแทก : Multiple 6 ft./1.8 m drop to concrete across full operating temperature range, multiple 8 ft. / 2.4 m drop to concrete at room temperature per MIL-STD 810G

Dimensions
6.3 in. L x 3.3 in. W x 1.1 in. D
161 mm L x 84 mm W x 28 mm D
Weight:  13.3 oz / 376 g
Display  :  4.7 in. High Definition (1280 x 720); exceptionally bright, outdoor viewable; optically bonded to touch panel
Imager Window    :  Corning Gorilla Glass
Touchpanel       Dual mode capacitive touch with stylus, finger or gloved fingertip input (conductive stylus sold separately); Screen Protector and Rain modes; Corning Gorilla Glass
Backlight  :  LED backlight
Power  :    Li-Ion 3.7 V, 4620 mAh. PowerPrecision/ PowerPrecision+: Improved battery technology for longer cycle times and real-time visibility into battery metrics for better battery management
Expansion Slot  :  User accessible MicroSD with 32 GB SDHC and up to 256 GB SDXC
SIM  :  TC77 only: 2 Nano SIM slots   (Dual SIM, Dual Stand-by - EU Only)
Network Connections  :
TC72: WLAN, WPAN (Bluetooth)
TC77: WWAN (cellular, WLAN (WiFi), WPAN (Bluetooth); USB 2.0 High Speed (host and client)
Notification  :  Audible tone; multi-color LEDs; vibration
Keypad  :  On-screen keypad and Enterprise Keyboard
Voice and Audio  :  Three microphone support with noise cancellation; vibrate alert; speaker; Bluetooth wireless headset support, high quality speaker phone; PTT headset support; cellular circuit switch voice; HD Voice

Performance Characteristics

CPU  :  Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System
TC72  :Android 10; upgradeable through A11/ R22
TC77  :Android 10; upgradeable through A11/ R22
Memory  :  4 GB RAM/32 GB Flash pSLC
Internet Protocol  :  IPv4 and IPv6

User Environment

Operating Temp.  :  -4° F to 122° F/-20° C to 50° C
Storage Temp.  :  -40°F to 158°F/-40°C to 70°C
Humidity  :  5% to 90% non-condensing
Drop Specifications  :  Multiple 6 ft./1.8 m drop to concrete across full operating temperature range, multiple 8 ft./2.4 m drop to concrete at room temperature per MIL-STD 810G
Tumble Specifications  :  2,000 3.3 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Sealing  IP65 and IP68 per applicable IEC sealing specifications
Vibration  :  4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random
(20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock  :  -40° F to 158° F/-40° C to 70° C rapid transition
Electrostatic Discharge (ESD)     +/-15kVdc air discharge; +/-8kVdc direct discharge; +/-8kVdc indirect discharge

Interactive Sensor Technology (IST)

Light Sensor       Automatically adjusts display backlight brightness
Motion Sensor  eCompass, 3-axis Gyro, 3-axis accelerometer
Atmospheric Pressure Sensor    Yes, TC77 only

Scanning
SE4770: 1D/2D omnidirectional imager
SE4750: 1D/2D omnidirectional imager
Digimarc Symbology support
Camera
Front — 5MP fixed focus
Rear — 13 MP autofocus; f/2.4 aperture; flash LED generates balanced white light; supports Torch mode; 4K video with image stabilization  Camera supports barcode scanning
NFC
ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P mode and Card Emulation via Host
SAM support for Calypso, Felica and Mifare technology TC77 only: Dual SAM support on TC77 SAM SKU

Wireless WAN Data and Voice Communications

TC77 Only: Radio Frequency Band
Supports VoLTE , Carrier Aggregation up to 3DL CA
AT&T FirstNet Ready certification
Verizon PNTM certification
LTE FDD: 700/800/850/900/1800/1900/AWS/2100/2600 (28,13,14,12,17/19,20/5,26/8/3/2,25/4,66/1/7);
LTE TDD: 1900/2300/2500 (39/40/41,38);
UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100 (5/8/4/2/1);
GSM/GPRS/EDGE: 850/900/1800/1900
GPS
TC77 only: Autonomous, Assisted GPS (A-GPS); Navstar; GLONASS; Gallileo; BeiDou

Wireless LAN

Radio    IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w; Wi-Fi™ certified; IPv4, IPv6, 2x2 MU-MIMO
Data Rates
5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps
Operating Channels
Channel 1-13 (2412-2472 MHz); Channel 36-165 (5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency
Security and Encryption              WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP.EAP-PWD
Multimedia        Wi-Fi Multimedia™ (WMM) and WMM-PS
Features             Soft AP, 2x2 MU-MIMO, 256 QAM Modulation on 5G GHz radio; Maximum Ratio Combining (MRC), Tx/Rx Low-Density Parity Check (LDPC), Transmit Beamforming(TxBF) and Beamformee (BFee) capability, Full IEEE 802.11 a/b/g/n legacy compatibility
Certifications    WFA (802.11n, WMM-PS, 801.11ac, PMF)
Fast Roam          PMKID caching; Cisco CCKM; 802.11r; OKC

Wireless PAN

Bluetooth          Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE)

Communication and Messaging

Workforce Connect PTT Express (included) provides instant push-to-talk small group communications across Wi-Fi networks. Workforce Connect PTT Pro (supported) provides a scalable network agnostic push-to-talk solution which also includes messaging, location services and two-way radio integration. Workforce Connect Voice client (supported) enables the TC72/TC77 Series to function as a full featured mobile telephone with multi line capability across Wi-Fi networks.
