ET50/ET55 Windows Specifications
Dimensions :
8.3 in. tablet: 9 in. W x 5.9 in. H x 0.5 in. D/
228 mm W x 150 mm H x 12.5 mm D
10.1 in. tablet: 10.6 in. W x 7:1 in. H x 0.5 in. D/
269 mm W x 181 mm H x 12.5 mm D
Weight : 8.3 in.: 1.2 bs. /555 g; 10.1 in.: 1.55 Ibs./750 g
Display : 8.3 in.: 21 cm and 10.1 in.: 25.6 cm; 1920x1200; Corning Gorilla Glass; active digitizer only 10.1 in.); outdoor viewable
Touch Panel : Capacitive 10 point multi-touch
Backlight : Ambient light sensor
Keypad Options : Virtual; Bluetooth@; USB
Expansion : Integrated connector to easily add accessories
Connectivity : Docking connector: USB 3.0, HDMI, charging; rugged connector for use with rugged dock Interfaces: full-size USB 2.0 connector, audio jack 3.5mm, JUSB (for charging)
Notification : LED flash; barcode decode; camera LED indicator
Audio : Stereo speakers and dual microphones (one front and one rear-facing)
PERFORMANCE CHARACTERISTICS
CPU : Intel quad core 1.59GHz (Turbo Frequency = 2.39GHz) Frequency supports 64 bit OS
Operating System : Windows10
Memory : 4GB LPDDR3 RAM; 64GB eMMC Flash;
User accessible micro SDXC card slot (standard supports up to 2TB)
USER ENVIRONMENT
Operating Temp. : 32 F to 122 F10 C to 50 C
Storage Temp. : -4 F to 140~F /-20 C to 60 C
Drop Specification : Standard: 3.28ft./1m drop to concrete without rugged frame With optional rugged frame: 5.9ft./1.8m to concrete per MIL-STD-810G
Sealing : IP65
Vibration : Operational: random vibration 10-1000 Hz, 1.9g RMS, 1 hour duration per axis. Non-operational: random vibration 10-1000Hz, 4.1g RMS
Humidity 10% to 90% RH (non-condensing)
POWER
Battery User Profile : Ample power for a full shift; continuous operation is enabled with the secondary optional battery
Battery : 8.3 in.: 5900mAh rechargeable Li-lon; user replaceable
10.1 in.: 8700mAh rechargeable Li-lon; user replaceable
Optional hot swappable 3.6V @ 6800mAh (24.4Whr) secondary battery available for 8.3 in. or 10.1 in. ET50/ET55
DATA CAPTURE
Scanning : Available through the expansion back accessory: SE4750 or SE4710 integrated advanced imagers with hardware decoding
Rear Camera : Image capture: 8MP auto-focus camera with user controllable LED flash, illumination and aiming; photographs, video, signatures and documents
Front Camera : 2MP 1080p full HD optimized for video collaboration and low lighting conditions
Video : 1080p (Full HD, 1920 x 1080), Frame rate = 30fps
PERIPHERALS AND ACCESSORIES
Accessories include: Share Cradles (4-slot); docking stations; vehicle mount cradle; single slot charge cradle; 4-slot optional battery charger; rugged frames; expansion back to easily add accessories (scanner/hand strap and optional battery bay or hand strap and optional battery bay); holster; replacement batteries, active stylus, screen protectors; charging cables and more
|
WIRELESS COMMUNICATIONS
WLAN : 802.11 a/b/g/n; dual band 2x2 MIMO for transmit and receive
WWAN : Global LTE with HSPA+ North America: AT&T LTE with AT&T (HSPA+) 3G fallback; Verizon LTE with EVDO fallback
WPAN : Class 2, Bluetooth v4.0 (Bluetooth Smart)
GPS : GNSS supports both GPS and Glonass with LTO technology for Assisted-GPS without sacrificing autonomous operation
NFC : P2P: ISO 18092; Reader/Writer: ISO 14443 -A-B, MIFARE, FeliCa@, ISO 15693, NFC Forum Tag
Types 1 to 4; Card emulation: ISO 14443 -A-B-B', MIFARE, FeliCa RF; distance up to 3 cm
SENSORS
Gyroscope : Maintains orientation based on principles of conservation of angular momentum
Motion Sensor : 3-axis accelerometer that enables motion-sensing applications for dynamic screen orientation and power management
Ambient Light Sensor : Automatically adjusts display brightness, keypad and display backlight
Electronic Compass : Independent - does not depend on GPS
SECURITY
FIPS TAA is compliant in optional SKU
|
