Physical Characteristics Mobile Computer TC51/TC56

Dimensions
6.1 in. L x 2.9 in. W x 0.73 in. H
155 mm L x 75.5 mm W x 18.6 mm H
Weight : 8.8 oz./249 g with battery
Display : 5.0 in. High Definition (1280 x 720); exceptionally bright, outdoor viewable; optically bonded to touch panel, 600 NITs
Imager Window : Corning Gorilla Glass
Touchpanel       Dual mode capacitive touch with stylus or bare or gloved fingertip input (conductive stylus sold separately); Corning Gorilla Glass 5
Backlight : LED backlight
Power   Rechargeable Li-Ion, Power Precision + Standard Capacity, 4300 mAh typical/4030 mAh minimum; improved battery technology for longer cycle times and real-time visibility into battery metrics for better battery management; fast USB charging (500mA)
Expansion Slot  User accessible MicroSD up to 32GB SDHC and up to 128 GB SDXC
SIM       1 Nano SIM slot (TC56 only)
Network Connections   WWAN, WLAN, WPAN (Bluetooth)
Notification       Audible tone; multi-color LEDs; vibration
Keypad  On-screen keypad and enterprise keyboard
Voice and Audio  : Two microphones with noise cancellation; vibrate alert; speaker; Bluetooth wireless headset support; High quality speaker phone; PTT headset support; cellular circuit switch voice; HD Voice
Buttons : Programmable back button; dual dedicated scan buttons; dedicated push-to-talk button, and volume up/down buttons

Performance Characteristics

CPU  : Snapdragon 650 64-bit hexa-core 1.8GHz ARM, Cortex A72, power optimization
Operating System : Android 8.1 Oreo
Memory
Standard: 2GB RAM/16GB Flash

Optional: 4GB RAM/32GB Flash

User Environment

Operating Temperature  : -4°F to 122°F/-20°C to 50°C
Storage Temperature    -40°F to 158°F/-40°C to 70°C
Humidity            5% to 85% non-condensing
Drop Specifications
Multiple 4 ft./1.2 m to tile over concrete over -10°C to 50°C (14°F to 122°F)
Multiple 6ft. drops to concrete with the rugged boot accessory per MIL STD 810 G
Tumble Specifications   500 1.6 ft./0.5 m tumbles, meets or exceeds IEC tumble specification
Sealing  IP67 and IP65 per applicable IEC sealing specifications
Vibration
4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random , (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock  -40° F to 158° F/-40° C to 70° C rapid transition
Electrostatic Discharge (ESD)     +/-15kv Air; +/-8kv contact; +/-8kv charge body

Interactive Sensor Technology (IST)
Light Sensor       Automatically adjusts display backlight brightness
Motion Sensor  3-axis Accelerometer with MEMS Gyro

Proximity Sensor
Automatically detects when the user places the handset against head during a phone call to disable display output and touch input

Data Capture
Scanning
SE4710 imager (1D and 2D) with extraordinary range:Scan range – Code 39 barcode:20 Mil: 1.8 in. to 32.0 in./4.5cm to 81.3 cm  3 Mil: 3.1 in. to 5.6 in./7.9 cm to 14.2 cm
CameraRear — 13 MP autofocus; f/2.4 aperture; rear camera flash LED generates balanced white light; supports Torch mode
NFC       ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P mode and Card Emulation via UICC and Host

Wireless Pan
Bluetooth          Class 2, Bluetooth v4.1 (Bluetooth® Smart technology); Bluetooth Wideband support HFPv1.6; Bluetooth v4.1 Low Energy (LE)
Wireless Wan Data and Voice Communications (TC56 Only)

Radio Frequency Band
Worldwide:
LTE: 700,800/900/1800/2100/2600 (FDD 28,20,8,3,1,7); UMTS/HSPA/HSPA+: 850/900/ AWS/1900/2100; GSM/GPRS/EDGE: 850/900/1800/1900
Americas:
LTE: 700/850/1900/AWS, (FDD 13,12,17,5,2,4); UMTS/HSPA/HSPA+: 850, 900, AWS, 1900, 2100 GSM/GPRS/EDGE: 850/900/1800/1900; CDMA: 850,1900 (BC0, BC1)
GPS       TC56 only: Integrated; Autonomous; Assisted GPS (A-GPS); Navstar; GLONASS; BeiDou

Wireless Lan
Radio    IEEE 802.11a/b/g/n/ac/d/h/i/k/r/w; Wi-Fi™ certified;IPv4, IPv6; 2X2 MIMO (TC51 only) 1x1 SISO (for TC56)
Data Rates
5GHz: 802.11a/n/ac — up to 866.7 Mbps (up to 433.3Mbps for TC56)
2.4GHz: 802.11b/g/n — up to 144 Mbps (up to 72.2Mbps for TC56)

Operating Channels
Channel 1-13 (2412-2472 MHz); Chan 36-165 (5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency

Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP
Data in Motion: FIPS 140-2 Level 1
Data at Rest: FIPS 140-2 Level 1

Certifications
WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast  WFA (Mobile AP / Personal Hotspot) - TC56 only
