Physical Characteristics Zebra Mobile Computer MC9200

Dimensions
9.4 in. L x 3.5 in. W x 7.4 in. H
240 mm L x 88 mm W x 189 mm H
Weight   26.9 oz./765g with battery
Display  4.3 in. WVGA (800 x 480), color display
Imager Window              Corning Gorilla Glass
Touchpanel       Dual mode capacitive touch with finger, gloved finger or stylus input (conductive stylus sold separately); screen protector (sold separately); Corning Gorilla Glass with air gap (standard model) or optically bonded (freezer model).
Backlight            LED backlit display
Power
Rechargeable Li-Ion: 3.6V, 7000mAh, (Freezer Capacity battery — 5000mAh)
Both batteries offer: PowerPrecision+ with improved battery technology for longer cycle times and real-time visibility into battery metrics for better battery management, fast charging (up to 2.4A); hot swap battery backup with temporary session persistence
Expansion Slot  User accessible MicroSD with 32GB SDHC and up to 256GB SDXC
Network Connections   USB 2.0 High Speed (Host & Client), WLAN and WPAN (Bluetooth)
Notification       Audible tone; Multi-color LED bar (between keyboard & display), haptic feedback
Keypad               Backlit, Field replaceable keypads; 58 Key Alpha-Numeric, 53 Key Alpha-Numeric STD, 53 Key Terminal Emulation (5250 and VT), 43 Key, 34 Key Numeric/Function, 29 Key Numeric/Calculation
Voice & Audio   Speaker, Microphone, PTT Voice (Internal Speaker and Bluetooth Wireless Headset Support).

Performance Characteristics

CPU       Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System           Android 10; upgradeable through A11/ R²
Memory             4 GB RAM/32 GB Flash pSLC

User Environment

Operating Temp.
Standard:   -4°F to 122°F/-20°C to +50°C,
Freezer:   -22°F to 122°F/-30°C to +50°C
Storage Temp.  -40°F to 158°F/-40°C to 70°C
Humidity
Standard: 5% to 95%, non-condensing;
Freezer: 5% to 95%, condensing (Condensation resistant model with integrated exit window heater)
Drop Specification
Standard: 10 ft. (3.1m) drops at room temperature per MIL-STD-810G, 8 ft. (2.4m) drops to concrete across temperature per MIL-STD-810G
Freezer: 7 ft. (2.1m) drops to concrete across temperature per MIL-STD-810G.
Tumble Specification     6,000 3.3 ft. (1m) tumbles; meets and exceeds IEC tumble specification.
Sealing  IP67 and IP65 per applicable IEC sealing specifications
Vibration            4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock  -40°F to 158°F (-40° C to 70°C) rapid transition
Electrostatic Discharge (ESD)
± 15kVdc air discharge; ± 8kVdc direct discharge;
± 8kVdc indirect discharge
Interactive Sensor Technology (IST)
Ambient Light Sensor     Automatically adjusts display and keypad backlight brightness
Motion Sensor  3-axis Accelerometer with MEMS Gyro

Data Capture

Scanning
SE965: 1D standard range laser scanner
SE4750: 1D/2D standard range omnidirectional imager
SE4770: 1D/2D standard range omnidirectional imager
SE4750 DPM : Direct Part Mark (DPM) imager
SE4850: 1D/2D extended range imager
Camera
Front: 5MP fixed focus, 2.0 aperture
Rear: 13MP autofocus, 2.2 aperture, flash LED generates balanced white light, support torch mode, supports rear camera barcode scanning
NFC       Tap to Pair, ISO 14443 Type A and B, Felica and ISO 15693 cards, P2P mode and Card Emulation via Host (HCE) support

Wireless LAN

Radio    IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/w; Wi-Fi certified; IPv4, IPv6, 2x2 MU-MIMO
Data Rates
5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps
Operating Channels
Channel 1-13 (2412-2472 MHz); Chan 36-165 (5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency
Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA/WPA2 Enterprise (TKIP and AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP, EAP-PWD
FIPS 140-2 Level 1: Data in Motion and Data at Rest
Multimedia        Wi-Fi Multimedia (WMM and WMM-PS; Including TSPEC)
Certifications    WFA (802.11n, WMM-PS, 802.11ac, PMF, WMM-AC, Voice Enterprise, WiFi Direct and WPS 2.0)
Fast Roam          PMKID caching; Cisco CCKM; 802.11r; OKC

Wireless PAN

Bluetooth          Class 2, Bluetooth V5.0 with BR/EDR and Bluetooth Low Energy (BLE) Support

Device Approvals and Compliance

TAA (Optional on select configurations)
Trade Agreement Act optional on select configurations Compliant, FIPS 140-2 (DIM and DAR) support; FIPS 140-2 Level 1: Data in Motion and Data at Rest
Non-Incendive (NI)1 (Optional on select configurations)
Suitable for use in Class I, II, III Div 2
Safety: cULus Listing — ISA/ANSA 12.12.01
Gases: Class I — Groups A, B, C, D
Dusts: Class II — Groups F, G
Fibers and Flyings: Class III
-20°C ≤ Ta ≥ +50°C T6
Communication and Messaging
Workforce Connect PTT Express (included) provides instant push-to-talk small group communications across Wi-Fi networks. Workforce Connect PTT Pro (supported) provides a scalable network agnostic push-to-talk solution which also includes messaging, location services and two-way radio integration. Workforce Connect Voice client (supported) enables the MC9300 to function as a full featured mobile telephone with multi-line capability across Wi-Fi networks featured mobile telephone with multi-line capability across Wi-Fi networks.

Environmental Compliance

Environment
• RoHS Directive 2011/65/EU; Amendment 2015/863
• REACH SVHC 1907/2006
