Physical Characteristics
Dimensions
4.5 in. W x 2.2 in. H x 0.55 in. D
114 mm W x 57 mm H x 14 mm D
Weight 3.88 oz./110 g
Display 3 in. color display FWVGA (854 x 480) IPS Transmissive TFT LCD
Touch Panel Capacitive touch with dual-touch operation (finger and glove)
Power Standard capacity, 1200mAh rechargeable Li-Ion, PowerPrecision+ battery (embedded)
Keys Scan; power; push-to-talk (PTT); volume; home (physical); recent apps; back (capacitive)
Notifications Audible tone; multi-color LEDs
Connectivity USB C (USB 2.0) and charge-only contacts — data transfer; charging
Performance Characteristics
CPU Qualcomm SnapdragonTM 660 octa-core 2.2 GHz
Operating System Android 10; upgradeable through A11/ R¹
Memory 4GB LPDDR4 SDRAM Discrete / 32GB MLC eMMC Flash
User Environment
Operating Temp. 32° F to 122° F/0° C to 50° C
Storage Temp. -40° F to 158° F/-40° C to 70° C
Humidity 5% to 95% non-condensing
Sealing IP54
Drop Specification 4 ft./1.2 m drop to smooth concrete across operating temperature
Tumble Specification 1,000 1.6 ft./0.5 m tumbles
Electrostatic Discharge (ESD)
+/-20 kVDC air discharge; +/-10 kVDC direct discharge; +/- 10 kVDC indirect discharge
Wireless Data Communications
WLAN/Radio 802.11 a/b/g/n/ac/r/k/d/h/i/w, IPv4, IPv6 2x2 MU-MIMO
Data Rates 5GHz: 802.11a/n/ac — up to 866.7 Mbps 2.4GHz: 802.11b/g/n — up to 300 Mbps
Operating Channels
Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
Channel 36-165 (5180-5825 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.
Security and Encryption WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA/WPA2 Enterprise (TKIP and AES) —EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP, EAP-PWD
Certifications WFA (802.11n, WMM-PS, 801.11ac, PMF)
Fast Roam PMKID caching; Cisco CCKM; 802.11r; OKC
WPAN Bluetooth 5.0 with Bluetooth Low Energy (BLE)
|
Voice and Audio
Audio Speaker: 1 Watt (90dB spl), integrated microphone, 3.5mm audio jack support (wired and Bluetooth headset support)
Push-to-Talk PTT (Workforce Connect PTT Express and Pro): via speaker/microphone on device and via headset VoIP (Workforce Connect Voice): via headset only Bluetooth audio supported (NB and WB)
Google Voice Entry
Google Voice Assist
PTT Express is Pre loaded and with 3 month trial license”
Data Capture
Scanning 1D/2D Imager (SE2100)
Sensor Technology
Magnetometer eCompass automatically detects direction and orientation
Motion Sensor 3-axis Accelerometer with MEMS Gyro
Gyroscope Detects linear acceleration of the EC30
Platforming
Mobility DNA, Enterprise Mobility Management (EMM) support
|
