DECODING CAPABILITY

1D / LINEAR CODES Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.

2D CODES Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code, Micro QR Code; China Han Xin Code

POSTAL CODES Australian Post; British Post; Canadian Post; China Post; Japanese Post; IMB; KIX Post; Planet

Code; Postnet; Royal Mail Code (RM4SCC)

STACKED CODES EAN/JAN Composites; GS1 DataBar Composites;
GS1 DataBar Expanded Stacked; GS1 DataBar

Stacked; GS1 DataBar Stacked Omnidirectional;MacroPDF; MicroPDF417; PDF417;UPC A/E Composites

ELECTRICAL

CURRENT Operating (Typical): 170 mA @ 5 VDC , Standby/Idle (Typical):
90 mA @ 5 VDC

INPUT VOLTAGE 5 VDC +/- 10%

ENVIRONMENTAL

AMBIENT LIGHT Up to 92,000 lux

DROP RESISTANCE Withstands repeated drops from 1.5 m / 5.0 ft
onto a concrete surface.

ESD PROTECTION (AIR DISCHARGE) 16 kV

HUMIDITY (NON-CONDENSING) 0 - 95%

PARTICULATE AND WATER SEALING IP42

TEMPERATURE Operating: 0 to 50 °C / 32 to 122 °F ,
Storage/Transport: -20 to 70 °C / -4 to 158 °F

INTERFACES

INTERFACES QW2470-BK: RS-232/Keyboard Wedge QW2420-BK: USB

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Black

DIMENSIONS 7.1 x 17.1 x 6.6 cm / 2.8 x 6.7 x 2.6 in

WEIGHT 120.0 g / 4.2 oz

READING PERFORMANCE

IMAGER SENSOR Field of View: 48 x 37º (H x V) Wide VGA: 640 x 480 pixels

LIGHT SOURCE Aiming: 1 Blue LED;Illumination: White LED 350 - 770 nm

MOTION TOLERANCE 20 IPS

PRINT CONTRAST RATIO (MINIMUM) 20%

READING ANGLE Pitch: +/- 65°; Roll (Tilt): +/- 360°; Skew (Yaw): +/- 65°

READING INDICATORS Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Good Read Feedback; Good Read LED

RESOLUTION (MAXIMUM) Code 39: 4 mils: 0.102 mm

PDF417: 6.6 mils: 0.168 mm

QR/Data Matrix: 7.5 mils: 0.191 mm

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol
length and scan angle.

Printing resolution, contrast, and ambient light dependent.

Code 39: 5 mils: 0.5 to 12.5 cm / 0.2 to 4.9 in

EAN/UPCA: 13 mils: 0.5 to 30.0 cm / 0.2 to 11.8 in

PDF417: 6.6 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in

Data Matrix: 10 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in

QR: 20 mils: 1.0 to 14 cm / 0.4 to 5.5 in

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a complete list of certifications.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to
EU RoHS

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is
available for download at no charge.

OPOS / JAVAPOS JavaPOS tilities are available for download at no
charge. OPOS Utilities are available for download at no

REMOTE HOST DOWNLOAD Lowers service costs and improves operations

DECODING CAPABILITY

1D / LINEAR CODES Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.

2D CODES Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code, Micro QR Code; China Han Xin Code

POSTAL CODES Australian Post; British Post; Canadian Post; China Post; Japanese Post; IMB; KIX Post; Planet

Code; Postnet; Royal Mail Code (RM4SCC)

STACKED CODES EAN/JAN Composites; GS1 DataBar Composites;GS1 DataBar Expanded Stacked; GS1 DataBar

Stacked; GS1 DataBar Stacked Omnidirectional;MacroPDF; MicroPDF417; PDF417;UPC A/E Composites

ELECTRICAL

CURRENT Operating (Typical): 170 mA @ 5 VDC , Standby/Idle (Typical): 90 mA @ 5 VDC

INPUT VOLTAGE 5 VDC +/- 10%

ENVIRONMENTAL

AMBIENT LIGHT Up to 92,000 lux

DROP RESISTANCE Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface.

ESD PROTECTION (AIR DISCHARGE) 16 kV

HUMIDITY (NON-CONDENSING) 0 - 95%

PARTICULATE AND WATER SEALING IP42

TEMPERATURE Operating: 0 to 50 °C / 32 to 122 °F ,Storage/Transport: -20 to 70 °C / -4 to 158 °F

INTERFACES

INTERFACES QW2470-BK: RS-232/Keyboard Wedge QW2420-BK: USB

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Black

DIMENSIONS 7.1 x 17.1 x 6.6 cm / 2.8 x 6.7 x 2.6 in

WEIGHT 120.0 g / 4.2 oz

READING PERFORMANCE

IMAGER SENSOR Field of View: 48 x 37º (H x V) Wide VGA: 640 x 480 pixels

LIGHT SOURCE Aiming: 1 Blue LED;Illumination: White LED 350 - 770 nm

MOTION TOLERANCE 20 IPS

PRINT CONTRAST RATIO (MINIMUM) 20%

READING ANGLE Pitch: +/- 65°; Roll (Tilt): +/- 360°; Skew (Yaw): +/- 65°

READING INDICATORS Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Good Read Feedback; Good Read

LED

RESOLUTION (MAXIMUM) Code 39: 4 mils: 0.102 mm

PDF417: 6.6 mils: 0.168 mm

QR/Data Matrix: 7.5 mils: 0.191 mm

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length and scan angle.

Printing resolution, contrast, and ambient light dependent.

Code 39: 5 mils: 0.5 to 12.5 cm / 0.2 to 4.9 in

EAN/UPCA: 13 mils: 0.5 to 30.0 cm / 0.2 to 11.8 in

PDF417: 6.6 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in

Data Matrix: 10 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in

QR: 20 mils: 1.0 to 14 cm / 0.4 to 5.5 in

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a complete list of certifications.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is available for download at no charge.

OPOS / JAVAPOS JavaPOS tilities are available for download at no charge. OPOS Utilities are available for download at no

 REMOTE HOST DOWNLOAD Lowers service costs and improves operations
