CORDLESS COMMUNICATIONS

DATALOGIC STAR2.0 CORDLESS SYSTEM™
Effective Radiated Power: 433.92 MHz;

Point-to-Point Configuration

RADIO FREQUENCY 433 MHz

RADIO RANGE (OPEN AIR) 25.0 m / 82.0 ft

DECODING CAPABILITY

1D / LINEAR CODES Autodiscriminates all standard 1D codes including

GS1 DataBar™ linear codes.

2D CODES Aztec Code; Aztec Mesas; Data Matrix; MaxiCode;

QR Code, Micro QR Code; China Han Xin Code

POSTAL CODES Australian Post; British Post; Canadian Post; China

Post; IMB; Japanese Post; KIX Post; Korea Post;

Planet Code; Postnet; Royal Mail Code (RM4SCC)

STACKED CODES EAN/JAN Composites; GS1 DataBar Composites;

GS1 DataBar Expanded Stacked; GS1 DataBar

Stacked; GS1 DataBar Stacked Omnidirectional;

MacroPDF; MicroPDF417; PDF417;

UPC A/E Composites

ELECTRICAL

BATTERY Battery Type: Lithium-Ion 1400 mAh;

Charge Time: External Power: < 3 hrs @ 12 VDC;

Reads per Charge: 30,000 +

INPUT VOLTAGE 4.75 - 14 VDC

ENVIRONMENTAL

AMBIENT LIGHT 0 - 100,000 lux

DROP RESISTANCE Withstands repeated drops from 1.5 m / 4.9 ft onto

a concrete surface.

ESD PROTECTION (AIR DISCHARGE) 16 kV

HUMIDITY (NON-CONDENSING) 5 - 95%

PARTICULATE AND WATER SEALING IP42

TEMPERATURE Operating: 0 to 50 °C / 32 to 122 °F

Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES

INTERFACES Keyboard Wedge / OEM (IBM) USB / RS-232 / USB

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Black, White

DIMENSIONS 16.3 x 9.1 x 4.1 cm / 6.4 x 3.6 x 1.6 in

WEIGHT Reader: 200 g / 7.1 oz

Base/Charger: 230 g / 8.1 oz

READING PERFORMANCE

IMAGER SENSOR Wide VGA: 752 x 480 pixels

LIGHT SOURCE Aiming: 2 Blue LED’s;

Illumination: Red LED 610 - 650 nm

MOTION TOLERANCE 25 IPS

PRINT CONTRAST RATIO (MINIMUM) 25%

READING ANGLE Pitch: +/- 65°; Roll (Tilt): 360°;

Skew (Yaw): +/- 60°

READING INDICATORS Beeper (Adjustable Tone and Volume);

Datalogic ‘Green Spot’ Good Read Feedback;

Good Read LED

RESOLUTION (MAXIMUM) 0.102 mm / 4 mils (Linear Codes)

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length

and scan angle.

Printing resolution, contrast, and ambient light

Code 39 5 mils: 0.5 to 15.0 cm / 0.2 to 5.9 in

EAN/UPCA 13 mils: 0.5 to 35.0 cm / 0.2 to 13.8 in

PDF417 6.6 mils: 2.0 to 15.0 cm / 0.8 to 5.9 in

Data Matrix 10 mils: 2.0 to 16.0 cm / 0.8 to 6.3 in

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a complete list of certifications.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is available for download at no charge.

OPOS / JAVAPOS JavaPOS Utilities are available for download at no charge.

OPOS Utilities are available for download at no charge.
