CORDLESS COMMUNICATIONS

DATALOGIC STAR CORDLESS SYSTEM™
Effective Radiated Power: 433.92 MHz: <10 mW; 910 MHz: <1 mW

Multi-Point Configuration: Max. Readers per

Radio Receiver: 16; Point-to-Point Configuration

RADIO FREQUENCY 433.92 MHz; 910 MHz

RADIO RANGE (OPEN AIR) 433.92 MHz: 30.0 m / 98.4 ft;

910 MHz: 15.0 m / 49.2 ft;

Two Way Communications

DECODING CAPABILITY

1D / LINEAR CODES Autodiscriminates all standard 1D codes

including GS1 DataBar™ linear codes.

POSTAL CODES China Post

STACKED CODES GS1 DataBar Expanded Stacked; GS1 DataBar

Stacked; GS1 DataBar Stacked Omnidirectional

ELECTRICAL

BATTERY Battery Type: Lithium-Ion, 2100 mAh

Charge Time: External Power: 4 Hours @ 12 VDC

Reads per Charge: 50,000

CRADLE INDICATOR LEDS Battery Charging (Red); Charge Completed

(Green); Power/Data (Yellow)

CURRENT Charging (Typical): < 8 W;

Operating (Typical): < 2.5 W @ 5 VDC;

Standby/Idle (Typical): < 2.5 mA @ 5 VDC

INPUT VOLTAGE 4.75 - 14 VDC +/- 5%

ENVIRONMENTAL

AMBIENT LIGHT 100,000 lux

DROP RESISTANCE Withstands repeated drops from 1.8 m / 5.9 ft

onto a concrete surface

ESD PROTECTION (AIR DISCHARGE) 16 kV

HUMIDITY (NON-CONDENSING) 5 - 95%

PARTICULATE AND WATER SEALING IP52

TEMPERATURE Operating: 0 to 50 °C / 32 to 122 °F;

Storage/Transport: -20 to 70 °C / -4 to 158 °F

INTERFACES

INTERFACES RS-232 / IBM 46XX / USB Multi-Interface

RS-232 / USB / Keyboard Wedge / Wand Multi-Interface

OPTIONAL FEATURES

COUNTERFEIT DETECTION BC4010-BK-910-CF; BC4010-BK-433-CF;

Field of View: 20º; UV LEDs: 8

Input Current (Maximum): 25 mA;

Optical Power: 19-26 mW @ 20 mA

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Black; White

DIMENSIONS Cradle: 18.6 x 9.9 x 5.6 cm / 7.3 x 3.9 x 2.2 in

Reader: 18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in

DISPLAY Display Type: GM4100-D Only: Graphic with backlight;

Font Dimensions: User selectable (4 lines x 16 columns default)

Screen Dimensions: 32 x 96 pixels

KEYPAD GM4100-D Only: 3-Key Keypad

WEIGHT Cradle: 246.0 g / 8.7 oz;

Reader (with Display): 246.0 g / 8.7 oz.

READING PERFORMANCE

LIGHT SOURCE Illumination: LED Array 630 - 670 nm

PRINT CONTRAST RATIO (MINIMUM) 15%

READ RATE (MAXIMUM) 325 reads/sec.

READING ANGLE Pitch: +/- 65°; Roll (Tilt): +/- 35°;

Skew (Yaw): +/- 65°

READING INDICATORS Beeper (Adjustable Tone and Volume); Datalogic

‘Green Spot’ Good Read Feedback; Good Read LED

RESOLUTION (MAXIMUM) 0.076 mm / 3 mils

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length and scan angle.

Printing resolution, contrast, and ambient light dependent.

5 mils: 6.0 to 18.0 cm / 2.3 to 7.0 in

7.5 mils: 3.5 to 30.0 cm / 1.4 to 11.7 in

10 mils: 2.0 to 45.0 cm / 0.8 to 17.7 in

13 mils: 3.0 to 60.0 cm / 1.2 to 23.4 in

20 mils: 3.0 to 80.0 cm / 1.2 to 31.2 in

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a complete list of certifications.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

LED CLASSIFICATION IEC 60825-1 Class 1 LED Product

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is available for download at no charge.

OPOS / JAVAPOS OPOS Utilities are available for download at no charge.

REMOTE HOST DOWNLOAD Lowers service costs and improves operations: BC4010
