Decoding Capability

1D / Linear Codes     Autodiscriminates all standard 1D codes
including GS1 DataBar™ linear codes

Postal Codes     Australian Post; British Post; Canadian Post;
 China Post; Japanese Post; KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)

Stacked Codes          EAN/JAN Composites; GS1 DataBar Composites;
GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;
GS1 DataBar Stacked Omnidirectional

Electrical

curre nt Operating (Typical): 340 mA @ 5 VDC

Standby/Idle (Typical): 190 mA @ 5 VDC

input voltage     5 VDC +/- 0.5 V

Environmental

Ambient Light         100,000 lux

Drop Resistance      Withstands repeated drops from 1.5 m / 5.0 ft
onto a concrete surface

ESD Protection (Air Discharge ) 16 kV

Humidity (Non-Condensing) 5 - 95%

Particulate and Water Sealing  IP42

Temperature              Operating: 0 to 50 °C / 32 to 122 °F

Storage/Transport: -40 to 70 °C / -40 to 158 °F

Interfaces

Interfaces QW2170-BK: RS-232 / Keyboard Wedge , QW2120-BK: USB

Physical Characteristics

Colors Available       Black

Dimensions               17.0 x 6.5 x 7.0 cm / 6.7 x 2.5 x 2.7 in

Weight      119.0 g / 4.2 oz

Reading Performance

Light Source              Red LED 610-650 nm

Print Contrast Ratio (Minimum ) 25%

Read Rate (Maximum ) 400 reads/sec.

Reading Angle          Pitch: +/- 65°; Roll (Tilt): +/- 45°; Skew (Yaw): +/- 70°

Reading Indicators   Beeper (Adjustable Tone); Datalogic ‘Green Spot’ ;Good Read Feedback; Good Read LED; Good Transmission

Resolution (Maximum ) 0.102 mm / 4 mils (1D Codes)

field of view               56° +/- 2°

Reading Ranges

Typical Depth of Field     Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.

5 mils : 2.5 to 15.0 cm / 1.0 to 6.0 in

7.5 mils : 0 to 24.0 cm / 0 to 9.4 in

10 mils: 0 to 35.0 cm / 0 to 13.8 in

13 mils: 0 to 40.0 cm / 0 to 15.7 in

20 mils: 0 to 60.0 cm / 0 to 23.6 in

Safety & Regulatory

Agency Approvals   The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a list of certifications.

Environmental Compliance     Complies to China RoHS; Complies to EU RoHS

Utilities

Datalogic Aladdin™ Datalogic Aladdin configuration program is available for download at no charge.

Opos / javaPOS JavaPOS Utilities are available for download at no charge.,OPOS Utilities are available for download at not charge
