DECODING CAPABILITY

1D / LINEAR CODES Autodiscriminates all standard 1D codes

including GS1 DataBar™ linear codes.

2D CODES Aztec Code; China Han Xin Code; Data Matrix;

MaxiCode; Micro QR Code; QR Code

POSTAL CODES Australian Post; British Post; China Post; IMB;

Japanese Post; KIX Post; Korea Post; Planet

Code; Postnet; Royal Mail Code (RM4SCC)

STACKED CODES EAN/JAN Composites; GS1 DataBar Composites;

GS1 DataBar Expanded Stacked; GS1 DataBar

Stacked; GS1 DataBar Stacked Omnidirectional;

MacroPDF; MicroPDF417; PDF417; UPC A/E

Composites

ELECTRICAL

CURRENT Operating (Typical): < 180 mA

Standby/Idle (Typical):

Automatic Object Sense Mode: 115 mA

Online & Serial OnLine Modes: 65 mA

INPUT VOLTAGE 5 VDC +/- 5%

ENVIRONMENTAL

AMBIENT LIGHT 0 - 100,000 lux

DROP RESISTANCE Withstands repeated drops from 0.76 m / 2.50 ft

onto a concrete surface

HUMIDITY (NON-CONDENSING) 5-95%

PARTICULATE AND WATER SEALING IP54

TEMPERATURE Operating: -20 to 50 °C / -4 to 122 °F

Storage/Transport: -20 to 70 °C / -4 to 158 °F

INTERFACES

INTERFACES OEM (IBM) USB; RS-232; USB: USB COM;

USB HID Keyboard

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Grey; Other colors and custom logo options are

available for minimum quantity purchase.

DIMENSIONS 3.9 x 5.7 x 5.8 cm / 1.5 x 2.2 x 2.3 in

WEIGHT (WITH CABLE) USB: 170 g / 6.3 oz

RS-232: 204 g / 7.2 oz

READING PERFORMANCE

IMAGE CAPTURE Graphic Formats: BMP, JPEG, TIFF;

Greyscale: 256, 16, 2

IMAGER SENSOR Wide VGA: 752 x 480 pixels

LIGHT SOURCE Aiming: 650 nm VLD

PRINT CONTRAST RATIO (MINIMUM) 25%

READING ANGLE Pitch: +/- 40°; Roll (Tilt): 180°; Skew (Yaw): +/- 40°

READING INDICATORS Beeper (Adjustable Tone); Datalogic ‘Green Spot’

Good Read Feedback; Good Read LED

RESOLUTION (MAXIMUM) 1D Linear: 0.102 mm / 4 mils

Data Matrix: 0.178 mm / 7 mils

PDF417: 0.102 mm / 4 mils

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length and scan angle.

Printing resolution, contrast, and ambient light

dependent. Code 39: 5 mil: 4.7 to 17.7 cm / 1.8 to 7.0 in

Code 39: 10 mil: 1.7 to 33.2 cm / 0.7 to 13.1 in

Data Matrix: 10 mil: 2.7 to 17.1 cm / 1.0 to 6.7 in

Data Matrix: 15 mil: 1.2 to 24.6 cm / 0.5 to 9.7 in

EAN: 13 mil: 2.5 to 41.9 cm / 1.0 to 16.5 in

PDF417: 10 mil: 2.2 to 23.9 cm / 0.9 to 9.4 in

QR Code: 10 mil: 3.5 to 16.0 cm / 1.4 to 6.3 in

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and regulatory approvals for its intended use.

The Quick Reference Guide for this product can be referred to for a complete list of certifications.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

LASER CLASSIFICATION Caution Laser Radiation - Do not stare into

beam; IEC 60825, Class2

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is available for download at no charge.

OPOS / JAVAPOS JavaPOS Utilities are available for download at no charge.

OPOS Utilities are available for download at no charge.

REMOTE HOST DOWNLOAD Lowers service costs and improves operations
