DECODING CAPABILITY

PD9130 GS1 DataBar™ linear codes, UPC/EAN, UPC/

EAN P2/P5 add ons, UPC/EAN Coupons, ISBN,

Code 128, EAN 128, Code 39, Code 39 Full ASCII,

Code 39 CIP, Code 32, Codabar, Interleaved 2 of 5,

IATA, Industrial 2 of 5, Standard 2 of 5, Code 11,

MSI, Plessey, Code 93, Follet 2/5, Code 4, Code 5,

Datalogic 2 of 5, Codablock F

ELECTRICAL

CURRENT Operating (Typical):

PD9130: 440 mA @ 4.5 V; 380 mA @ 5 V;

75 mA @30 V

INPUT VOLTAGE 4.5 - 30 VDC

ENVIRONMENTAL

AMBIENT LIGHT Immune to light exposure in offices/facilities and

direct exposure to sunlight

DROP RESISTANCE Withstands 50 drops from 2.0 m / 6.6 ft to

concrete

ESD PROTECTION (AIR DISCHARGE) 20 kV

HUMIDITY (NON-CONDENSING) 0 - 95%

PARTICULATE AND WATER SEALING IP65

TEMPERATURE Operating: -20 to 50 °C / -4 to 122 °F

Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES

INTERFACES Keyboard Wedge; RS-232; USB

PHYSICAL CHARACTERISTICS

COLORS AVAILABLE Yellow/Black

DIMENSIONS 21.2 x 11.0 x 7.4 cm / 8.4 x 4.3 x 2.9 in

WEIGHT 340.0 g / 11.9 oz

READING PERFORMANCE

LIGHT SOURCE Green LED

PRINT CONTRAST RATIO (MINIMUM) 15%

READING ANGLE Pitch: +/- 75°; Roll (Tilt): +/- 45°;

Skew (Yaw): +/- 70°

READING INDICATORS Beeper; Datalogic Three Green Lights (3GL™)

Good Read Feedback: Datalogic ‘Green Spot’ on

the Code, Dual Good Read LEDs

RESOLUTION (MAXIMUM) 2.5 mils

READING RANGES

TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length

and scan angle. Printing resolution, contrast and

ambient light dependent.

Code 39

5 mils: 3.0 to 32.0 cm / 1.2 to 12.6 in

7.5 mils: 2.0 to 48.0 cm / 0.8 to 18.9 in

10 mils: 2.0 to 66.0 cm / 0.8 to 26.0 in

20 mils: 3.0 to 110.0 cm / 1.2 to 43.3 in

40 mils: 3.0 to 230.0 cm / 1.2 to 90.6 in

EAN 13

2.0 to 61.0 cm / 0.8 to 24.0 in

Note: Reading performances may change with

different symbologies

SAFETY & REGULATORY

AGENCY APPROVALS The product meets necessary safety and

regulatory approvals for its intended use.

See the Regulatory Addendum for details.

ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

LED CLASSIFICATION Product compliant according to IEC 62471

UTILITIES

DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is

available for download at no charge.

OPOS / JAVAPOS JavaPOS and OPOS Utilities are available for

download at no charge.

REMOTE HOST DOWNLOAD Available on request
