Specifications
Decoding Capability
1D / Linear Codes : Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes
2D Codes : Aztec Code; Data Matrix; MaxiCode; QR Code
Stacked Codes : GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MicroPDF417; PDF417

Electrical
Current : Operating (Typical) : < 350 mA , Standby/Idle (Typical): < 250 mA
Input Voltage  : 5 VDC (+/- 10%)

Environmental
Ambient Light
Indoor : 0 to 6,000 lux;
Outdoor: 0 to 86,000 lux
Drop Resistance : Withstands repeated drops from 1.2 m / 4.0 ft onto a concrete surface
ESD Protection (Air Discharge) : 20 kV
Humidity (Non-Condensing) : 5 - 95%
Particulate and Water Sealing : IP52
Temperature :
Operating : 0 to 40 °C / 32 to 104 °F
Storage/Transport : -40 to 70 °C / -40 to 158 °F

Interfaces
RS-232; USB: OEM USB, USB COM, USB HID Keyboard, USB TEC

Optional Features
EAS Features : Checkpoint Systems: Integrated EAS hardware will work with Counterpoint IV, V, VI and VII models , Sensormatic: Good Read Acknowledgement
Value Added Features : Advanced Label Editing; Diagnostic Reporting; Host Download

Physical Characteristics
Colors Available : Black; White; Other colors and custom logo options are available for minimum quantity purchase.
Dimensions : 15.1 x 7.6 x 10.9 cm / 5.9 x 3.0 x 4.3 in
Weight : 306.2 g / 10.8 oz

Reading Performance
Image Capture :
Optional : 752 x 480 pixels; Graphic Formats: JPEG
Print Contrast Ratio (Minimum) : 25%
Reading Angle : Pitch: +/- 60°; Roll (Tilt): 0 - 360°; Skew (Yaw): +/- 60°
Reading Indicators : Beeper (Adjustable Tone and Volume); Good Read LED
Resolution (Maximum) : 0.130 mm / 5 mils

Reading Ranges
Typical Depth of Field : Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.
1D / Linear Codes
5 mils: 0 to 2.5 cm / 0 to 1.0 in
7.5 mils: 0 to 8.2 cm / 0 to 3.2 in
10 mils: 0 to 12.7 cm / 0 to 5.0 in
13 mils UPC: 0 to 15.2 cm / 0 to 6.0 in
2D Codes
6.6 mils PDF417: 0 to 7.6 cm / 0 to 3.0 in
10 mils Data Matrix: 0.6 to 3.1 cm / 0.2 to 1.2 in
10 mils PDF417: 0 to 12.7 cm / 0 to 5.0 in
15 mils PDF417: 0 to 15.2 cm / 0 to 6.0 in
24 mils Data Matrix: 0 to 12.7 cm / 0 to 5.0 in

Safety & Regulatory
Agency Approvals  :
The product meets necessary safety and regulatory approvals for its intended use.
The Quick Reference Guide for this product can be referred to for a complete list of certifications.
Environmental Compliance : Complies to China RoHS; Complies to EU RoHS

Utilities
Magellan™ OSP : Magellan On-Screen Programming (OSP) configuration software is available for download at no charge.
OPOS / JavaPOS : JavaPOS Utilities are available for download at no charge. OPOS Utilities are available for download at no charge.
Remote Host Download : Lowers service costs and improves operations.
