Performance

Image Sensor Linear imager or Laser

Interface RS-232, USB, PS/2

Symbologies

Code128, EAN-13, EAN-8, Code 39, UPC-A,UPC-E, Codabar, Interleaved 2 of 5, ISBN, Code 93,UCC/EAN-128, GS1 Databar, etc.

Resolution ≥ 5mil

Light Source 620nm Visible Red LED

Scan Rate 300 scans per second

Illumination 0 ~ 80,000 LUX

Symbol Contrast ≥ 30%

Scan Angle**

Pitch ±55°@ 0°Roll and 0° Skew

Roll ±25°@ 0°Pitch and 0° Skew

Skew ±75°@ 0°Roll and 0° Pitch

Mechanical/ Electrical

Operating Voltage DC 5.0V

Current

Maximum 150mA

Operating 120mA

Standby 45mA

Colors Black or white

Weight 105g

Environmental

Operating Temperature 0℃ to 50℃

Storage Temperature -40℃ to 60℃

Humidity 0 to 95% ( non-condensing )

Drop 1.5 m drops to concrete

Certifications

FCC Part15 Class B, CE EMC Class B

Accessories

Stand The scanner can be mounted on the stand for hands-free scanning.

Flex Cable

RS-232 Cable Equipped with a power connector; used to connect the scanner to a host device.

USB Cable Used to connect the scanner to a host device.

PS/2 Cable Used to connect the scanner to a host device.

Power Adaptor

Used to provide power for the scanner.

Output: DC5V,1.5A; Input: AC100~240V, 50~60Hz.
