Performance
Image Sensor : 1280×960 CMOS
Illumination : White LED
Aiming : 650nm laser diode

Symbologies
2D : PDF417, QR Code, Data Matrix, Aztec, Maxicode, etc.
Postal : USPS Postnet, Royal Mail, KIX Post, Australian Postal, etc.
1D : EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128,
Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard
2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey,
Plessey, etc.

Resolution*: ≥3mil
Typical Depth of Field*
EAN-13 : 40mm-410mm
Code 39 : 110mm-250mm
PDF417 : 115mm-190mm
QR Code : 70mm-280mm
Motion Tolerance* : 2m/s
Scan Angle** : Pitch: ±50°, Roll: 360°, Skew: ±50°
Field of View : Horizontal 40.5°, Vertical 30.4°
Symbol Contrast* : ≥25%

Mechanical/Electrical
Interfaces : RS-232, USB, PS/2
Dimensions : 74.0(W)×115.0(D)×161.0(H)mm
Weight : 173g
Notification : Beep, LED indicator, vibration
Rated Power Consumption : 1251mW (typical)
Operating Voltage : 5VDC±5%
Current@5VDC:
Operating : 266mA (typical), 344mA (max.)
Standby : 109mA

Operating Temperature : -20℃ to 50℃ (-4°F to 122°F)
Storage Temperature : -40℃ to 70℃ (-40°F to 158°F)
Humidity : 5%~95% (non-condensing)
ESD : ±8 KV (contact discharge); ±16 KV (air discharge)
Drop : 1.8m
Sealing : IP42

Certifications
FCC Part15 Class B, CE EMC Class B

Accessories
Cable
USB : Used to connect the HR42 to a host device.
RS-232 : Used to connect the HR42 to a host device.
Power Adapter : DC5V power adapter to power the HR42 with RS-232 cable.
Output: DC5V, 1.5A Input: AC100-240V, 50-60Hz

*Test conditions: T=23℃; Illumination=300lux using incandescent lamp; sample barcodes made by Newland.
**Test conditions: Scan Distance= (min. DOF + max. DOF)/2; T=23℃; Illumination=300lux using incandescent lamp; 2D: QR Code; 10 Bytes; Resolution=15mil; PCS=0.8.
Specifications are subject to change without notice.Data Matrix 100mm-250mm
