Performance

Image Sensor        1280x800 CMOS

IlluminationWhite LED

Depth of Field EAN13 (13mil)    5-195mm

Depth of Field QR (15mil)          5-165mm

Minimal Print Contrast    25%

Scan Angle Roll     360°

Scan Angle Pitch   ±50°

Scan Angle Skew  ±45°

Field of View Horizontal  51°

Field of View Vertical       32°

Motion Tolerance  2.5m/s

Data capture

1D      EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc.

2D      PDF417, Data Matrix, QR Code, Micro QR Code, Aztec, etc.

Physical

Dimensions (mm)  83(W)x81(D)x148(H)mm

Weight         293g

Interfaces     RS-232, USB

Notifications          Beep, LED indicator

Input Voltage         5VDC±5%

Current @ 5VDC Operating        219mA (typical)

Power Consumption        1041mW (typical)

Environmental

Operating Temperature   -20°C to 60°C

Storage Temperature       -40°C to 70°C

Humidity      5% to 95% (non-condensing)

Electro Static Discharge (ESD)  ±14 kV (air discharge), ±8 kV (direct discharge)

Drop  1.2m

Sealing        IP52

Device Management

Software      EasySet (configuration)

Certifications

Certifications         FCC Part15 Class B, CE EMC Class B
