Performance

Image Sensor        1280×800 CMOS

IlluminationWhite LED & Red LED

Aiming         Green LED

Depth of Field EAN13 (13mil)    50mm-495mm

Depth of Field PDF417 (6.67mil)             70mm-215mm

Depth of Field Data Matrix (10mil)       50mm-220mm

Min. Symbol Contrast      25%

Scan Angle Roll     360°

Scan Angle Pitch   ±55°

Scan Angle Skew  ±55°

Field of View Horizontal  39°

Field of View Vertical       24°

Scan ModesManual Mode, Sense Mode, Continuous Mode

Data capture

1D      Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey, etc.

2D      PDF417, QR Code, Data Matrix, Chinese Sensible Code

Physical

Dimensions (mm)  Scanner:113.5×73.0×159.0mm Cradle:195×82.5×47mm

Weight         Scanner: 217g (including battery) Cradle:150g

Material        PC, ABS

Interfaces     RS-232, USB

Battery Type          2200mAh lithium-ion battery

Expected Charge Time    4 hours

Notifications          Beep, LED indicator

Input Voltage         5VDC±5%

Power Supply Input         DC 5V, 500mA

Power Supply Output      AC100 ~ 240V, 50~60Hz

Environmental

Operating Temperature   -20℃ to 60℃ (-4°F to 140°F）

Storage Temperature       -40°C to 70°C (-40°F to 158°F)

Humidity      5%~93% (non-condensing)

Drop Scanner: 1.2m/3.9ft   Cradle: 1m/3.3ft

Wireless

Radio Technology  Bluetooth 5.0

Communication Distance          50m (in open space)

Communication Modes     Synchronous, asynchronous and batch modes

Accessories

Optional      RS232 Cable

Standard      USB Cable

Certifications
