Performance

Image Sensor 1280×800 CMOS

Illumination  White LED

Aiming 650nm laser diode

Symbologies
2D:   PDF417, QR Code, Data Matrix, Aztec, Maxicode, etc.

Postal: USPS Postnet, Royal Mail, KIX Post, Australian Postal, etc.

1D:   EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 25,Standard 25, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc.

Resolution ≥3mil

Motion Tolerance* Max. 50cm/s

Typical Depth of Field

EAN-13 (13mil):    30mm-550mm

Code 39 (5mil):     90mm-230mm

PDF417 (6.7mil):    110mm-210mm

Data Matrix (10mil): 100mm-220mm

QR Code (15mil):   30mm-370mm

Scan Angle Roll: 360°, Pitch: ±55°, Skew: ±55°

Min. Symbol Contrast 20%

Field of View Horizontal 42°; Vertical 28°

Mechanical/ Electrical

Interfaces RS-232, USB

Dimensions (L×W×H) Scanner: 95.5×77.5×172.5mm

Weight Scanner: 227g

Notification Beep, LED, vibration

Power Supply Voltage for Charging 5VDC±5%

Environmental

Operating Temperature -20°C to 50°C (-4°F to 122°F)

Storage Temperature -40°C to 70°C (-40°F to 158°F)

Humidity 5%~95% (non-condensing)

ESD ±15KV (air discharge); ±8KV (direct discharge)

Drop Scanner: 1.8m   Cradle: 1.0m

Sealing Scanner: IP54

Wireless

Communication Modes Automatic Batch and Manual Batch modes

Radio Technology Bluetooth 5.0

Communication Distance ≥50m (in open space)

Memory Capacity 1MB (capable of storing the data of over 20,000 EAN-13 barcodes)

Battery 2200mAh lithium-ion battery

Expected Battery Life ≥12 hours of continuous operation (scan once per 6 seconds)

Expected Charge Time ≤4 hours (with power adapter)

Certifications FCC Part15 Class B, CE EMC Class B
