Performance

Image Sensor : 640x480 CMOS/ 752×480 CMOS
Symbologies :
2D: PDF417, QR Code, Data Matrix, etc.
1D: Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, ISSN, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar, etc.
Resolution ≥5mil

Typical Depth of Field
EAN-13 (13mil) 60mm-380mm
Code 39 (5mil) 60mm-190mm
Data Matrix (10mil) 85mm-140mm
QR Code (15mil) 40mm-190mm
PDF417 (6.7mil) 85mm-150mm
Scan Angle : Pitch: ±55°; Roll: 360°; Skew: ±55°
Min. Symbol Contrast  : 30%
Interface : Micro USB, Bluetooth HID/SPP/BLE profiles
Bluetooth Transmission Range : 50m (open space)
Wireless Standards :  2.4 - 2.5GHz ISM band, compatible with Bluetooth 4.0/3.0/2.1+EDR
Memory Capacity :  1MB (capable of storing the data of over 20,000 EAN-13 barcodes)

Mechanical/Electrical
Dimensions :  88.0(L)×46.0(W)×24.5(H)mm
Weight :  62g
Notification : Sound, LED and vibration
Battery :  3.7V 900mAh rechargeable Li-ion battery
Expected Battery Life : 6 hours of continuous operation (Synchronous mode,scan and send data once per 6s)
Expected Charge Time : 3.5 hours
Power Adapter (optional) Output: DC 5V, 500mA Input: AC100 ~ 240V, 50~60Hz
Current : Operating Current: 260mA (Bluetooth is on) Standby Current: 10mA

Environmental
Operating Temperature  : -20°C to 50°C (-4°F to 122°F)
Storage Temperature : -40°C to 70°C (-40°F to 158°F)
Humidity  : 5%~95% (non-condensing)
ESD :  ±8 KV (Contact discharge); ±15 KV (Air discharge)
Drop  : 1.2m
Sealing  : IP42

Certifications  : FCC Part15 Class B, CE EMC Class B
