Dimensions (L x W x H)
215.5 mm x 78.5 mm x 28 mm (8.48 in x 3.09 in x 1.1 in)

Weight
415 g (14.64 oz) with battery pack

Operating Temperature
-10°C to +50°C (+14°F to +122°F)

Storage Temperature
-20°C to +60°C (-4°F to +148°F)

Humidity
10% to 90% relative humidity (non-condensing)

Drop
1.5 m (5 ft) to concrete at room temp (10°C to 50°C [50°F to 122°F]) per MIL-STD 810G

Tumble
Exceeds 1,000 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification

ESD
±12 kV Air and ±8 kV Direct

Environmental Sealing
IP64 (IEC 60529)

Processor
Qualcomm 8917 1.4 GHz quad-core

Memory
2 GB RAM, 16 GB Flash

Operating System
Android 7.1 without GMS

Display
10.2 cm (4.0 in) High Definition (480 x 800) bright color LCD with backlight, optically bonded to touch panel

Touch Panel
CTP multi-touch touch panel

Keypad
30-key numeric physical keypad with 4 function keys

Audio
Rear speaker >85 dB at 10 cm (3.9 in); front panel microphone for audio recording; Bluetooth® wireless headset support

I/O Ports
Standard Micro USB 2.0

Sensors
Ambient Light Sensor, Proximity Sensor, Accelerometer, Hall Sensor

Storage Expansion
User-accessible microSD card up to 32 GB (SDHC/SDIO-compliant)

Battery
Li-Ion, 3.7V, 5100 mAh

Hours of Operation
12+ hours

Charging Time
About 5 hours

Scan Notification
Red/green light

Decode Capabilities
1D Laser SKU: N4313
2D SKU: N5603ER High-Performance 2D Imager:
Capable of scanning all common 1D and 2D barcodes

Application Software
Honeywell Power Tools and Demos Honeywell ECP (Enterprise Client Pack: Terminal Emulator, Enterprise Browser, and Launcher): Preloaded for all SKUs; some SKUs pre-licensed for 12 months

Battery Condition LED
Red/Green/Blue

WLAN
IEEE 802.11 a/b/g/n/ac

WLAN Security
WEP, 802.1x, TKIP, AES, PEAPv0, PEAPv1, EAP-M, SCHAPv2, EAP-GTC, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2

Bluetooth
Bluetooth Class 4.1

USB Communication Cable: Micro USB 2.0 (communicates to PC, supports adaptor/USB charging)
USB Wall Adaptor: 5V/2A power adaptor with power plugs
Hand Strap

Single Charging Cradle
Four-Bay Terminal Charging Cradle
Four-Bay Battery Charger
Replacement Battery
Scan Handle
Hand Strap
