Mechanical/Environmental
Dimensions 8.8˝ x 3.4˝ x 2˝ (223mm x 86mm x 50mm)
Weight 21oz (595g) w/ radio, battery, and SR laser scanner
Operating Temperature 14° to +122°F (-10° to +50°C)
Storage Temperature -4° to +158°F (-20° to +70°C)
Humidity 5 to 100% relative humidity condensing at 104°F (40°C)
Drop Multiple
5 ft. (1.5m) drops to concrete (w/ handle);
6 ft. (1.8m) w/ rubber boot accessory (w/o handle)
Environmental Sealing
Independently certified to meet IP65 standards for moisture and particle resistance
ESD Air: ±15 KV; Contact: ±8 KV

System Architecture

Processor PXA320 806 MHz
Operating System
Microsoft® Windows® Mobile 6.5, Microsoft® Windows® CE 6.0
Memory 256MB SDRAM x 256MB Flash
Optional Software
Wavelink TE, RFTerm® (TN5250,TN3270) VT220), AppLock utility controls user application access and unwanted
configuration changes, multiple language OS support, voice recognition, Wavelink Avalanche and LXE eXpress
Config compatible, Stay-Linked Ready
Display 3.5˝ (88 mm) 240x320 ¼ VGA TFT color LCD
Touch Panel Industrial touch panel with resistive touch and support for finger touch and stylus
Keypad Backlit 55-key alphanumeric and 32-key numeric shifted alpha

Audio

Audio for headset, voice recognition application certified. Speaker w/ adjustable volume control
I/O Ports RS-232/USB 2.0/audio out/charging connector
Storage Expansion User accessible SD memory card slot. Supports 1GB or 4GB SD memory cards.
Battery Full shift battery life with typical usage 2200mAh@7.4V
Imager/Scanner
Standard Range Area Imager with High Visibility Aimer, Base Laser Engine, Standard Laser Engine, Multi-Range
Extended Range Engine
Decode Capabilities Reads standard 1D and 2D symbologies
Development Environment Honeywell SDK for Windows® Embedded
Service Plans Optional three- and five-year service programs offer worry-free mobile computing

Wireless Connectivity

WLAN 802.11 a/b/g
WLAN Security WPA, WPA2 (Personal and Enterprise), 802.11x, EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2,
PEAPv1/EAP-GTC, WMM, CWG-RF Profile, CCX v.4, WAPI
WLAN Antennas Internal antenna diversity
WPAN Bluetooth® 2.0+EDR
