Dimensions (L x W x H)
214 mm x 118 mm x 21 mm (8.4 in x 4.6 in x 0.83 in)

Weight
550 g (1.21 lb) with standard battery pack
640 g (1.41 lb) with extended battery pack

Operating Temperature
-10°C to 50°C (14°F to 122°F)

Storage Temperature
-20°C to 70°C (-4°F to 158°F)

Humidity
10% to 90% relative humidity (non-condensing)

Drop
1.2 m (4 ft) to concrete at room temp (10°C to 50°C) per MIL-STD 810G

Tumble
Exceeds 200 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification

ESD
±12 kV Air and ±8 kV Direct

Environmental Sealing
IP64 (IEC 60529)

Processor
1.8 GHz Qualcomm® SDM450 8-core (EDA71)
1.2 GHz Qualcomm MSM8916 quad-core (EDA70)

Operating System
Android 8 (Oreo), upgradeable to Android Q (EDA71)
Android 7.1 Nougat (EDA 70)

Memory
2/4 GB RAM, 32/64 GB Flash  (EDA71)
2 GB RAM, 16 GB Flash (EDA70)

Display
7-inch high definition (1280 x 720) bright color LCD with backlight, outdoor viewable, optically bonded to touch panel

Touch Panel
Rugged, multi-touch capacitive touch panel, optically bonded for extra durability and better sunlight viewability. Automatic detection and configuration utilizing mutual and self-capacitance modes for water rejection and use

Keypad
On-screen keypad, side scan triggers, volume up/down, power button

Audio
Built-in speaker, Bluetooth wireless headset support

I/O Ports
eHomebase: 3 x USB host, 1 x USB client, Ethernet, spare battery charger
USB Vehicle Dock: 1 x USB host

Camera
13-megapixel color camera with autofocus (EDA71)

5.0-megapixel color camera with
autofocus (EDA70)

Sensors
Ambient light sensor, proximity sensor, accelerometer

Storage Expansion
User-accessible microSD card up to 32 GB SDHC, and up to 128 GB SDXC (EDA71)

User-accessible microSD card up to 32
GB (SDHC/SDIO-compliant) (EDA70)

Battery
Li-ion, 3.8 V, 4000 mAh and 8850 mAh with integrated battery diagnostics

Hours of Operation
8+ hours

Scanning
1D/2D imager options: N3601 (standard) or N6703 (enhanced)

Application Software
Honeywell power tools and demos, Honeywell SDKs for Android

WWAN
GSM & EDGE: Band2/Band3/Band5/ Band8 (EDA71)
WCDMA: Band1/Band2/Band4/Band5/ Band8/Band9/Band19 (EDA71)
CDMA1x&EVDO: BC0/BC1/BC6 FDD-LTE: Band1/Band2/Band3/Band4/ Band5/Band7/Band8/Band9/Band12/ Band13/Band17/Band19/Band20/ Band26/Band28/Band30 (EDA71)
TDD-LTE: Band38/Band39/Band40/ Band41 (EDA71)

WLAN
IEEE 802.11 a/b/g/n/ac; 2x2 MIMO; Wi-Fi certified (EDA71)

IEEE 802.11 a/b/g/n; Wi-Fi certified (EDA70)

Additional WLAN Features
802.11 d/e/h/i/k/r/u/w (mc with Android P)

WLAN Security (Android)
OPEN, WEP, WPA/WPA2 (personal and enterprise)

Supported EAP
TLS, PEAP, TTLS, PWD, FAST, LEAP

Bluetooth
Class 2 V4.2 Bluetooth

Bluetooth Profiles
HFP, PBAP, A2DP, AVRCP, OPP only

NFC
Integrated Near Field Communication

VoIP
Supported

VPN
IPSec V4/L2TP, PPTP

GPS Supported Protocols
GNSS receiver for BeiDou, GPS and GLONASS
