Physical Characteristics
Dimensions with either standard or extended
battery:
15.4 x 7.4 x 2.8 cm (6.05 x 2.93 x 1.09”)
Weight:
With extended battery: 340 gm (12 oz)
Environmental
Operating Temp: -10° C to +50° C (14° F to +122° F)
Storage Temp: -20° C to +70° C (-4° F to +158° F)
Charging Temp: +5° C to +30° C
Relative Humidity: Non-condensing, 95%
Rain & Dust Resistance: IP54
Drop Spec: 26 drops from 1.5m (5 ft) to concrete across the operating temperature range per MIL-STD 810G
Tumble Spec: 1,000 0.5 m (1.6 ft) tumbles at
room temperature
Electrostatic Discharge: +/- 15kV air discharge,
+/- 8kV direct discharge
Power
Extended Battery Pack: 3.7V, 3900 mAh;
Batteries are IEEE 1725 compliant, Li-Ion,
removable, rechargeable.
Operating system
Window Mobile 6.1 or Windows Embedded Handheld 6.5
Microprocessor
Qualcomm MSM 7600, 528 MHz (Mulit-processor architecture)
Memory and Storage
Memory: 256 MB RAM
(approx 150MB available for user applications)
ROM: 512 MB Flash
(approx 350 MB available for user applications)
Customer-accessible micro-SD slot for removable memory cards up to 32 GB
Display
• 3.5”, 240 x 320 pixel (QVGA) trans-reflective
TFT-LCD display
• 65,536 (16bit RGB) colors
• LED backlight
• Touch screen
Standard Communications
USB – High Speed 2.0
|
Software
Device Management: Contains Intermec Smart
Systems Client and is compatible with most popular 3rd party device management solutions
Application Development: Support Windows APIs and Intermec Developer Libraries
Integrated Radios
Wireless WAN: (Contains the Flexible Network™ radio that can be reprogrammed to convert between the UMTS and CDMA radio formats)
• 3.75G UMTS / HSUPA
• 3.5G CDMA: 1xEV-DO Rev. A
UMTS Frequencies Supported - MHz: 850, 1700,
1900, 2100
GSM/GPRS Frequencies Supported - MHz: 850, 900, 1800, 1900
Technology Class UTMS: 3.75G HSUPA
Max Speeds: Uplink - 2.0 Mbps; Downlink - 7.2 Mbps
Technology Class CDMA: 3.5G EV-DO Rev A
Max Speeds: Uplink - 1.8 Mbps; Downlink - 3.1 Mbps
Antenna: Internal
Wireless LAN: IEEE®802.11 b/g
Data rates: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48 and 54 Mbps
Operating channels: 1 to 13 (2412-2472 MHz)
and 14 (2484 MHz)
Regulatory compliance: As per IEEE® 802.11d
Antenna: Internal
Security: WiFi Certified for WPA/WPA2 operation.
Authentication: PEAP/MS-CHAPv2, EAP-TLS
Encryption: WEP (64 or 128 bit), AES, TKIP
Wireless PAN: Integrated Bluetooth Class II,
Ver 2.1+EDR
Operating channels: 0 to 78 (2402-2480 MHz)
Data Rates: 1, 2, 3 Mbps
Antenna: Internal
Global Positioning System and Digital Compass
12 channel Integrated GPS; Supports Autonomous mode with extended ephemeris data; Supports assisted operation via WAN Carrier; Network independent; <3m accuracy.
Integrated, independent Digital Compass
provides directional information based
on earth’s magnetic field.
Accelerometer
Embedded accelerometer enables automatic
or application specific features such as “screen
rotation” or system suspend/resume
|
Audio Support
Support for Speech recognition / PTT applications; Front and rear speakers; rear speaker has >70dB at 40cm (15.7 in); Front panel microphone for voice communication; Wireless Bluetooth headset support
Integrated Scanner
EA11 Imager with “laser like” linear line aimer that is capable of scanning 5 mil 1D and 5 mil 2D barcodes EA21 Imager with 1 megapixel area imager with laser aimer/framer, 8 bit grayscale, capable of scanning 6 mil 1D and 10 mil 2D barcodes. Supports Enhanced Mobile Document Imaging (eMDI) – optional Intermec software application
Integrated Camera
3.1 Megapixel color camera with autofocus;
includes flash
Keypad Options
Numeric or QWERTY with backlit keypad
Accessories
Desktop AC adapter/Comm adapter (with USB port); Vehicle power adapter; Vehicle holder; RAM mount; Single dock, USB Host/Client (optional Ethernet module); Quad battery charger; Four-bay multi-docks (charge only or charge and Ethernet); Magnetic stripe reader (snap-on)
Regulatory Approvals and Compliance
Safety: cULus Listed, CDRH, D, CE, NOM
EMC: Class B – FCC/ICES/CE
Radio: FCC ID, Industry Canada TAC, CE0984, A-tick (AU), C-tick (NZ), NCC, OFTA, IDA
HAC: FCC
Others: HKSI, BSMI, ICASA, POSTEL, NTC, ETA, GOST, SIRIM, ANATEL, EU Directives –WEEE, RoHS, Batteries & Accumulators, Packaging & Waste Packaging
|
