Dimensions
L x W x D: 21.6 cm x 8.3 cm x 2.8 cm (8.53 in x 3.29 in x 1.12 in)

Weight
401 g (14.1 oz) with 2000 mAh battery

Operating Temperature
-10°C to +50°C (+14°F to +122°F)

Charging Temperature
+5°C to +35°C (+41°F to +95°F)

Storage Temperature
-20°C to +70°C (-4°F to +158°F)

Humidity
Non-condensing, 95%

Drop Survival
Multiple 1.5 m (5 ft) drop to concrete at ambient; multiple 1.2 m (4 ft) to concrete across the operating temperature range per MIL-STD 810G

Tumble Specification
1,000 (0.5 m) tumbles per IEC 60068-2-32 specification

Electrostatic Discharge
+/- 15 kV air discharge, +/- 8 kV direct discharge

Rain and Dust Resistance
IP54, category 1

Microprocessor
Texas Instruments 1GHz multi-engine processor architecture

Operating System
Microsoft Windows Embedded Handheld built on Windows 6.5.3 technology with Honeywell HTML5 Browser. Available via download at the Honeywell Developer Library.

Memory and Storage
Flash ROM: 512MB
Memory/Storage Extensions: Customer-accessible micro-SD slot for removable memory cards up to 32GB
RAM Memory: 256MB RAM

Keypad
Both keypad options feature backlit hard keycaps with laser-etched legends; backlit automatically controlled via ambient light sensor.

• 8.9 cm (3.5 in) Transmissive QVGA
• 240 x 320 pixels
• 65,536 (16 bit RGB) colors
• High-durability touch screen
• LED backlight
• Ambient light sensor

• Included – User removable, rechargeable Lithium-Ion; 3.7V, 2000 mAh (7.4 Watt-hours)
• Optional – Removable, rechargeable Lithium-Ion; 3.7V, 5100 mAh (18.5 Watt-hours)
• Optional – Removable, rechargeable Lithium-Ion; 3.7V, 5200 mAh (18.5 Watt-hours) Smart Pack

Scanning Performance
Scan Engine Options: EA31 high performance motion-tolerant 2D Imager; (up to 400 in/s) white LED illumination Capable of scanning all common 1D and 2D bar codes; 1D as small as 4 mils; 2D as small as 6.6 mils Refer to User’s Manual for depth- of- field performance.

Accessories
Supports most CK3 charging and docking accessories as well as FlexDock modular docking system, vehicle dock and holder, snap on adaptors and removable scan handle.

USB – Full Speed 2.0 OTG, USB – Full Speed 2.0 Client

Wireless Wireless
LAN: IEEE 802.11 b/g/n WLAN
Security: WiFi Certified for WPA and WPA2
Authentication: 802.1x
Cisco Compatibility: CCXv4
Encryption: WEP (64- or 128- bit), AES, TKIP

Wireless PAN: Integrated Bluetooth Class II, Version 2.1+EDR
Operating Channels: 0 to 78 (2402 - 2480MHz)
Data Rates: 1, 2, 3 Mbps
Antenna: Internal
