PHYSICAL CHARACTERISTICS

Dimensions
LI3608-SR
Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D

18.5 cm H x 7.6 cm W x 13.2 cm D

Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D

18.5 cm H x 7.6 cm W x 14.2 cm D

Weight
LI3608-SR
Corded: 10.1 oz./287 g

Cordless: 13.6 oz./386.5 g
LI3608-ER
Corded: 11.5 oz./327 g

Cordless: 15.0 oz./424 g

Input Voltage Range
LI3608-SR
Host powered: 4.5 VDC min., 5.5 VDC max.

External power supply: 11.4 VDC min., 12.6 VDC max.

LI3608-ER
Host powered: 4.5 VDC min., 12.6 VDC max.

External power supply: 11.4 VDC min., 12.6 VDC max.

Operating Current
LI3608 (corded): 170 mA (RMS typical)
LI3608 (corded): 250 mA (RMS typical)

Standby Current
LI3608 (corded): 40 mA (RMS typical)
LI3608-ER (corded): 110 mA (RMS typical)

Color Industrial Green

Supported Host  Interfaces USB, RS232, Keyboard Wedge Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Std TCP/IP

Battery PowerPrecision+ 3100 mAh Li-Ion rechargeable battery

User Indicators Direct decode indicator; LEDs; beeper; vibration

PERFORMANCE CHARACTERISTICS

Scans per Full Charge 140,000+ (LI3608SR) , 100,000+ (LI2608ER)

Illumination Two (2) 617nm Amber LEDs (LI3608 SR), 660 nm LED (LI2608ER)

Imager Field of View 35⁰(LI3608 SR), 30.7⁰(LI3608 ER)

Image Sensor 1,500 pixels (LI3608 SR), 2,496 pixels (LI3608 ER)

Minimum Print Contrast 15% minimum reflective difference (LI3608 SR), 25% minimum reflective difference (LI3608 ER),

Skew/Pitch/Roll Skew: ±65⁰,Pitch: ±65⁰,Roll: ±45⁰

DECODE CAPABILITIES**

1D Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

USER ENVIRONMENT

Operating Temp.
Corded: -22⁰F to 122⁰F/-30⁰C to 50⁰C

Cordless: -4⁰F to 122⁰F/-20⁰C to 50⁰C

Storage Temp. –40⁰F to 158⁰F/-40⁰C to 70⁰C

Humidity 5% to 95% non-condensing

Drop Specification Withstands multiple 8.0 ft. / 2.4 m drops to concrete

Tumble Specification 5,000 tumbles @ 3.3 ft. (1 m)

Sealing : Scanner IP65 and IP67, FLB cradle: IP65

USER ENVIRONMENT (CONTINUED)

ESD
Per EN61000-4-2, ±25 KV air discharge, ±10 KV

direct discharge, ±10 KV indirect discharge

Ambient Light Immunity
LI3608 SR
0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight)

LI3608 ER
0 to 10,000 Foot Candles/0 to 107,639 Lux (direct sunlight)

WIRELESS CONNECTIVITY

Bluetooth Radio Bluetooth Class 1, Version 4.0 (LE), serial port and HID profiles

Data Rate
3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth

1 Mbit/s (0.27 Mbit/s) for Low Energy

Radio Range
Direct line of sight in open air: Class 1: Minimum 300 ft. (100.0 m); Class 2: Minimum 30 ft. (10.0 m)

REGULATORY

Environmental RoHS EN 50581: 2012

Electrical Safety
EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013

International Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013

US/Canada Safety (: UL 60950-1, second edition,CAN/CSA-C22.2 No. 60950-1-07

LED Safety LI3608 SR : International LED Safety: IEC 62471: 2006 (Ed.1.0); EN 62471: 2008 (LED)
Laser/LED Safety LI3608 ER :Complies with 21 CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice NO. 50,dated June 24, 2007 and IEC/EN 60825-1:2007 and/or IEC/EN 60825-1:2014

EMI/RFI
IT Emissions: EN 55022: 2010/AC: 2011 (Class B)

IT Immunity: EN 55024: 2010

Heavy Industrial: EN 61000-6-2: 2005/AC:2005

Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B)

Voltage Fluctuation and Flicker: EN 61000-3-3: 2013

Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified)

Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B

Digital Apparatus: ICES-003 Issue 5, Class B
