PHYSICAL CHARACTERISTICS
Dimensions
4.39 in. L x 1.79 in. W x 1.02 in. H
11.15 cm L x 4.55 cm W x 2.6 cm H
Weight With batteries: 3.28 oz./93.2 g
Scan Engine SE4710 image engine
Memory 512 MB Flash
Memory Capacity Over 1 million bar codes (UPC with time date stamp)
LEDs Scan LED (Green, Red, and Amber) and Bluetooth® LED (Blue)
Four LED battery status indicator
Buttons Scan, remove scan (batch mode
only), enable Bluetooth (RF scanners only), battery status; scan button tested to a million depressions, all other buttons tested to 250,000 epressions

OPERATING MODES
Batch Scans recorded with optional time/date stamp
Open Bluetooth Real time wireless data transmission

BATTERY
Battery 950 mAh Lithium ion
Charge Time 3 hours 40 minutes
Battery Life
Batch: 24 hours use or 8,500 scans (6 scans per minute on full charge)
Standby: 3 months Bluetooth 12 hours use or 4,250 scans (6 scans per minute on full charge)

PERFORMANCE CHARACTERISTICS
Decode Capability 1D and 2D symbologies
Interfaces Supported USB (micro jack): Bluetooth
Real Time Clock A date/time stamp can be recorded with each bar code scanned (batch mode operation only)
Batch Communication USB 2.0

USER ENVIRONMENT
Drop Specification Multiple 5 ft./1.5 m drops to concrete
Tumble Specification 250 cycles @ 1.64 ft./0.5 m (500 drops)
Sealing IP42
Operating Temperature 32° to 104° F/0° to 40° C
Storage Temperature -40° to 158° F/-40° to 70°C
Humidity 10 to 95% noncondensing

USER ENVIRONMENT (CONTINUED)
Ambient Lighting Tolerance
Tolerant to typical artificial indoor and natural outdoor (direct sunlight
) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED1: 450 ft. candles (4,844 Lux) Sunlight: 8,000 ft. candles (86,111 Lux)

BLUETOOTH
Bluetooth Radio Bluetooth, Class 1/Class 2, Version 2.1 + Enhanced Data Rate (EDR)
Bluetooth Range 300 ft./100 m when configured for Class 1 or 30 ft./10 m when configured for Class 2
Bluetooth Profiles HID keyboard wedge and Serial Port Profile (SPP) and Wireless SSI (proprietary)

ACCESSORIES
BT-CS1-0BR Bluetooth Dongle for Bluetooth Class 1 Version 2.0 enables connection to host by simply scanning a bar code; CHS5000-1000CR Charge Cradle charges one scanner and one battery simultaneously;
CHS5000-8000CR Charge Cradle charges up to eight scanners; SAC5000-8000CR Charge Cradle charges up to eight batteries; lanyard

REGULATORY
Laser Safety IEC62471:2006 (Ed.1.0); EN62471 :2008 (LED)
IEC62471:2006 (Ed .1.0); EN62471:2008 (LED) EMC
FCC Part 15 Class B, ICES 003 Class B, EN 55022, EN 55024, EN 301 489-1, EN 301 489-17
Radio EN 300 328
Electrical Safety UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1
Environmental EN50581

DECODE RANGE
4 mil Code 39: 2.9 in. / 7.4 cm — 8.4 in. / 21.4 cm
5 mil Code 128: 2.4 in. / 6.1 cm — 7.8 in. / 19.8 cm
5 mil 39: 1.6 in. / 4.1 cm — 13.1 in. / 33.3 cm
5 mil PDF417: 2.7 in. / 6.9 cm — 8.0 in. / 20.3 cm
10 mil Data Matrix: 2.5 in. / 6.4 cm — 9.7 in. / 24.7 cm
100% UPCA: 1.4 in. / 3.6 cm* — 25.6 in. / 65.0 cm
20.0 mil Code 39: 1.6 in. / 4.1 cm* — 29.6 in. / 75.2 cm
*Minimum distance determined by symbol length and scan angle
