PHYSICAL CHARACTERISTICS
Dimensions : 3.41 in. L x 1.95 in. W x .87 in. H 8.65 cm L x 4.95 cm W x 2.2 cm H
Weight With batteries: 2.45 oz./70 gm
Scan Engine : SE955 laser, single line
Memory : 512MB Flash
Memory Capacity : Over 1 million barcodes (UPC with time date stamp)
LEDs : Scan LED (Green, Red, and Amber) and Bluetooth® LED (Blue)
Buttons : Scan, remove scan (batch mode only), enable Bluetooth (RFscanners only)

OPERATING MODES
Batch : Scans recorded with optional time/date stamp
Open Bluetooth : Real time wireless data transmission

BATTERY
Battery : 780 mAh Lithium ion
Charge Time : 3 hours
Battery Life : Batch - 24 hours use or 8,500scans (6 scans per minute on full charge)Standby - 3 months Bluetooth - 12 hours use or 4,250 scans (6 scans per minute on full charge)
Power Consumption : 5V, 500mA max while charging

PERFORMANCE CHARACTERISTICS
Decode Capability : 1-D symbologies
Interfaces Supported USB (Mini jack): CS3000 and CS3070,Bluetooth: CS3070
Real Time Clock : A date/time stamp can be recorded with each bar code scanned (Batch mode operation only)
Batch Communication :USB 2.0

BLUETOOTH
Bluetooth Radio : Bluetooth, Class 2, Version 2.1 + Enhanced Data Rate (EDR)
Bluetooth Range : 30 ft./10 m
Bluetooth Profiles : HID keyboard wedge and Serial Port Profile (SPP)

USER ENVIRONMENT
Drop Specification : 4 ft./1.21 m drop to tiled linoleum over concrete, 6 drops per 6 sides,across the operating temperature range
Tumble Specification : 250 cycles @ 1.64 ft./0.5 m (500 drops)
Operating Temperature : 32° to 104° F /0° to 40° C
Storage Temperature : -40° to 158° F /-40° to 70°C
Humidity : 10 to 95% noncondensing
Ambient Lighting Tolerance : Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent,Incandescent, Mercury Vapor,Sodium Vapor, LED : 450 Ft Candles (4,844 Lux) Sunlight:8000 Ft Candles (86,111 Lux)

REGULATORY
Laser Safety : EN 60825-1, IEC 60825-1, 21CFR1040.10
EMC
CS3000: FCC Part 15 Class B,ICES 003 Class B, EN 55022, EN 55024
CS3070: FCC Part 15 Class B,ICES 003 Class B, EN 55022, EN 55024, EN 301 489-1, EN 301 489 -17
Radio: CS3070: EN 300 328
Electrical Safety : UL 60950-1, C22.2 No. 60950-1,EN 60950-1,
IEC 0950-1
Environmental : RoHS Directive 2002/95/EEC

DECODE RANGE
4 mil: 0.90 – 4.90 in. / 2.3 – 12.4 cm
5 mil: 1.20 – 7.40 in. / 3.0 – 18.8 cm
7.5 mil: 1.60 – 12.40 in. / 4.1 - 31.5 cm
10 mil: 1.60 – 17.40 in. / 4.1 – 44.2 cm
100% UPC: 1.60 – 23.40 in. / 4.1 – 59.4 cm
15 mil: 1.60 – 24.40 in. / 4.1 – 62.0 cm
20 mil: 1.90 – 25.40 in. / 4.8 – 64.5 cm
40 mil: *- 27.40 in. / * - 69.6 cm
55 mil: *- 31.40 in. / * - 79.8 cm
