Standard Features
• Print methods: Thermal Transfer or Direct Thermal
• ZPL and EPL programming languages
• 5 status icon, 3 button user interface
• Ethernet, Serial, USB 2.0, USB Host
• Printer setup mobile app for Android & iOS via BLE
(Bluetooth Low Energy 5) connection*
* BLE is intended for use with Zebra printer setup mobile app only
• Real Time Clock (RTC)
• Media dancer for excellent print quality
• OpenACCESS™ for easy media loading
• Dual-wall frame construction
• ENERGY STAR® certified
• ZebraDesigner Essentials – easy label design tool free at
www.zebra.com/zebradesigner
• PDF Direct
• Two-year standard warranty
Physical Characteristics
| Dimension |
Direct Thermal:
8.7 in. L x 7.0 in. W x 5.9 in. H
221 mm L x 177 mm W x 151 mm H
Thermal Transfer:
10.5 in. L x 8.0 in. W x 7.5 in. H
267 mm L x 202 mm W x 192 mm H |
| Weight |
Direct Thermal: 3.6 lbs./1.6 kg
Thermal Transfer: 5.5 lbs./2.5 kg
|
Printer Specifications
| Operating System |
Link-OS® |
| Resolution |
203 dpi/8 dots per mm
300 dpi/12 dots per mm (optional) |
| Memory |
512 MB Flash; 256 MB SDRAM
64 MB user available non-volatile memory
8 MB user available SDRAM |
| Maximum Print Width |
4.09 in./104 mm for 203 dpi
4.27 in./108 mm for 300 dpi |
| Maximum Print Speed |
8 in./203 mm per second (203 dpi)
6 in./152 mm per second (300 dpi) |
| Media Sensors |
Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor |
| Firmware |
ZPL II; EPL 2; XML; ZBI; PDF Direct |
Media and Ribbon Characteristics
| Label Length |
Maximum: 39.0 in./991 mm
Minimum: 0.25 in./6.4 mm |
| Media Width |
Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm
Thermal Transfer: 0.585 in./15 mm to 4.65 in./118 mm |
| Media Roll Size |
Maximum outer diameter: 5.0 in./127 mm
Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters |
| Media Thickness |
0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max. (tear-off mode only) |
| Media Types |
Roll-fed or fan-fold, die cut or continuous with or without black mark, label or tag stock, continuous receipt paper, wristbands, linerless media*
* For use only with linerless printer model |
| Ribbon Outside DIameter |
2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m) |
| Ribbon Standard Length |
984 ft. (300 m); 243 ft. (74 m) |
| Ribbon Ratio |
1:4 ribbon to media (300 m)
1:1 ribbon to media (74 m) |
| Ribbon Width |
1.33 in./33.8 mm — 4.3 in./109.2 mm |
| Ribbon Core I.D. |
300 meter ribbon 1 in./25.4 mm
74 meter ribbon 0.5 in./12.7 mm |
|
Operating Characteristics
| Operating Temp. |
40° to 105° F/4.4° to 41° C |
| Storage Temp. |
-40° to 140° F/-40° to 60° C |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Humidity |
5% to 95% non-condensing |
| Electrical |
Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR certified; Energy Efficiency Level VI certified; optional 2750 mAh battery; Healthcare models include IEC60601-1 certified power supply |
Options and Accessories
| Media Handling |
Dispenser/Peeler: label peel and present with label present sensor (factory installed or field installable)
Cutter (factory installed or field installable)
|
| Communications |
802.11ac Wi-Fi and Bluetooth 4.1 (dual radio), (factory installed or field installable)
|
| User Interface |
4.3” full color touch LCD (resolution: 480 wide x 272 high) with 3-button user interface |
| Battery |
Provides power to the printer to support a full shift of printing at maximum print speed; supports all connectivity and media handling options |
| Carrying Case |
Carrying case with shoulder strap and handles makes it easy to bring your desktop printer and battery to the point of application |
| Keyboard Display Unit |
Zebra Keyboard Display Unit (ZKDU) for stand-alone printing solutions |
| Media Locking Cabinet |
Mechanical lock with 2 keys; Kensington® lock slot; available on ZD621 healthcare direct thermal model only |
| Mounting Plate |
Secure ZD Series printers to countertops or shelves |
| Enclosed Power Supply |
Attached power supply accessory for cord-free installation |
Fonts/Graphics/Symbologies
|
Bar Code Ratios
|
2:1 and 3:1 |
| 1D Bar Codes |
Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code |
| 2D Bar Codes |
Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec |
| Fonts and Graphics |
16 resident expandable ZPL II bitmap fonts, two resident scalable ZPL fonts, five resident expandable EPL2 fonts, native open-type font support, Unicode compliant. China units include SimSun simplified Chinese font |
|
