คุณสมบัติอย่างย่อ Barcode Scanner Honeywell 1980i

คุณสมบัติหลัก Main specification Honeywell Granit 1980i

Mechanical

Dimensions (LxWxH)  : 133 mm x 75 mm x 195 mm (5.2” x 2.9” x 7.6”)
Weight  : 335 g (11.8 oz)

Electrical
Input Voltage :  4.0 to 5.5 VDC
Operating Power   :  2.35 W (470 mA @ 5.0 V)
Standby Power :  0.5 W (100 mA @ 5.0 V)
Host System Interfaces   :  USB and True RS232

Environmental
Operating Temperature  :   -30°C to 50°C (-22°F to 122°F)
Storage Temperature   :  -40°C to 70°C (-40°F to 158°F)
Humidity  :   0 to 95% relative humidity, non-condensing
Drop   :  Designed to withstand 50 2m (6.5’) drops to concrete at -30°C
Tumble   :  5,000 1m (40˝) tumbles
Environmental Sealing   :  IP65
Light Levels  :   0 to 100,000 lux (9,290 foot-candles)
ESD  :   ±20Kv air discharge, ±8kV contact discharge

Scan Performance
Scan Pattern  :   Area Imager
Scan Angle
  Horizontal: 12.9°
  Vertical: 8°
Symbol Contrast
  1D Codes: 30% minimum reflectance difference
  2D Codes: 40% minimum reflectance difference
Min. Resolution 1D & 2D Codes  :   2 mil
Pitch, Skew :  70°, 80°
