TECHNICAL SPECIFICATIONS
CORDLESS MODELS COMMUNICATIONS

QuickScan QM2500 :
Datalogic STAR Cordless System
Effective Radiated Power: 433.92 MHz < 6.3 mW;
910 MHz < 50 mW; Point-to-Point Configuration;
Radio Frequency: 433.92MHz; 910 MHz; Two Way
Communications; Radio Range (Open Air): 30.0 m / 98 ft

QuickScan QBT2500 :
Bluetooth Wireless Technology
Profiles: SPP (Serial Port Profile); Protocol: Bluetooth 4.0
Certified Class 1; Radio Frequency: 2.4 GHz; Radio Range
(Open Air): 50.0 m / 164 ft; Range distances are measured
using the base station. Range with connection to other
Bluetooth peripherals may show different results.
Security: Data Encryption; Scanner Authentication

DECODING CAPABILITY
1D / Linear Codes :
Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.

2D Codes :
Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot code

Postal Codes :
Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)

Stacked Codes :
EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Digital Watermarking :
Digimarc Barcodes (QD2500, QM2500, QBT2500 only)

CORDED MODELS ELECTRICAL
Current : Operating: < 400 mA @ 5V; Standby/Idle: < 90 mA @ 5V
Input Voltage : 5 VDC

CORDLESS MODELS ELECTRICAL
Battery :
Battery Type: Lithium-Ion: 3250 mAh
Charge Time (Scanner only): Type-C External Power: 3 Hours;
Charge Time (via Cradle): External Power: 4 Hours @ 12 VDC;
Reads per Charge: 115,000

Cradle Indicator LEDs :
Battery Charging (flashing orange or green);
Charge Completed (steady green)

Current : Charging (Typical): Scanner only: 500mA @ 3.7 V (Operative)
Cradle only (BC2090): 45 mA @ 5 V (Operative)

Input Voltage : 5V+/-5% (Scanner) in Type-C Port 4.5 – 14 VDC +/- 5% (Cradle BC2090)

ENVIRONMENTAL
Ambient Light : 0 - 110,000 lux

Drop Resistance : Withstands repeated drops from 1.5 m / 5.0 ft onto a crete surface.

Trigger Resistance : Withstands 10 Mhits

ESD Protection (Air Discharge) : 16 kV

Humidity (Non-Condensing) : 0 - 95%

Particulate and Water Sealing : IP52

Temperature Operating: 0 to 50 °C / 32 to 122 °F

Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES
Interfaces
CORDLESS MODELS:
BC2090: USB Type C / USB / RS-232 / Keyboard Wedge Multi-Interface

CORDED MODELS:
QD2590: USB Type C / USB / RS-232 / Keyboard Wedge Multi-Interface
QW2520, QD2520: USB type C / USB only

PHYSICAL CHARACTERISTICS
Colors Available : QD2500 Black, White; QW2500: Black

Dimensions
CORDLESS MODELS:
Scanner only: 15.9 x 6.8 x 10.7 cm / 6.2 x 2.7 x 4.2 in
CORDED MODELS:
14.8 x 6.8 x 12.6 cm / 5.8 x 2.7 x 4.96 in

Weight :
145.0 g / 5.1 oz (corded models)
206.5 g / 7.3 oz (cordless models, battery included)

READING PERFORMANCE
Image Capture :
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2

Image Sensor :
QD2500, QM2500, QBT2500: 1 Megapixel (1280 x 800 pixels)
QW2500: VGA (640 x 480 pixels)

Light Source
Aiming: Blue LED emission 468 nm
Illumination: Red LED emission 617 nm

Motion Tolerance : 30 IPS

Print Contrast Ratio (Minimum) :
QD2500, QM2500, QBT2500: minimum 15%
QW2500: minimum 15% with specific configuration

Reading Angle : Pitch: +/- 65°; Roll (Tilt): 360°; Skew (Yaw): +/- 65°

Reading Indicators : Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Good-read feedback on the code; Good-read LED

Resolution (Maximum)
QD2500, QM2500, QBT2500:
1D Linear: 0.077 mm / 3 mils;
PDF417: 0.077 mm / 3 mils;
Data Matrix: 0.127 mm / 5 mils;
QR Code: 0.17 mm / 6.7 mils
QW2500:
1D Linear: 0.077 mm / 3 mils;
PDF417: 0.127 mm / 5 mils;
Data Matrix: 0.152 mm / 6 mils;
QR Code: 0.17 mm / 6.7 mils

READING RANGES
Typical Depth of Field :
Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.

QD2500, QM2500, QBT2500:
Code 39: 5 mils: 0.5 to 25.0 cm / 0.2 to 9.8 in
Code 39: 10 mils: 0.5 to 38.0 cm / 0.2 to 14.9 in
Data Matrix: 10 mils: 0.5 to 21.5 cm / 0.2 to 8.5 in
EAN/UPCA: 13 mils: 0.5 to 51.0 cm / 0.2 to 20.1in
PDF417: 6.7 mils: 0.5 to 21.0 cm / 0.2 to 8.3 in
QR Code: 20 mils: 0 to 37.0 cm / 0 to 14.6 in

QW2500:
Code 39: 5 mils: 0.5 to 23.0 cm / 0.2 to 9.0 in
Code 39: 10 mils: 0.5 to 37.0 cm / 0.2 to 14.5 in
Data Matrix: 10 mils: 1.0 to 15.5 cm / 0.39 to 6.1 in
EAN/UPCA: 13 mils: 1.0 to 40.0 cm / 0.39 to 15.7 in
PDF417: 6.7 mils: 0.5 to 13.5 cm / 0.2 to 5.3 in
QR Code: 20 mils: 1.0 to 33.0 cm / 0.39 to 12.9 in

SAFETY & REGULATORY
Agency Approvals :
The product meets necessary safety and regulatory approvals for its intended use.
The Quick Reference Guide for this product can be referred to for a complete list of certifications.

Environmental Compliance : Complies to China RoHS; Complies to EU RoHS

LED Classification : Illuminator Exempt group, Aiming Risk Group 1 according to IEC 62471

UTILITIES
Datalogic Aladdin™ :  Datalogic Aladdin configuration program is available for download at no charge.

OPOS JavaPOS  : JavaPOS and OPOS Utilities are available for download
at no charge.

Remote Host Download : Lowers service costs and improves operations.
