Specifications
Printer Specifications
Print Method
Direct Thermal
Print Speed
Up to 4 ips (102 mm/sec - Liner)
Up to 3 ips (76 mm/sec - Linerless)
Print Resolution
203 dpi
Print Width
Up to 104 mm
Sensing
Paper End
Gap
Black Mark
Paper Cover Open

Media Characteristics
Media Type
Liner, Linerless (Optional)
Media Width
112 mm / 105 mm (Optional)
Media Roll Diameter
Up to 56 mm
Media Thickness
0.07 ~ 0.19 mm
Supply Method
Easy Paper Loading

Physical Characteristics
Dimensions (WxDxH)
143 x 138 x 66 mm
(5.63 x 5.44 x 2.60 inch)
Weight
Including battery: 530 g (1.17 Ibs.)
Paper: 242 g (0.53 lbs.)
Electrical
7.3 V Li-ion, 2850 mAh (Nominal),
Rechargeable Charging time: Up to 4 hrs
EnergyStar Certified

Performance Characteristics
Memory
128 MB SDRAM, 256 MB Flash
256 MB SDRAM, 512 MB Flash (Optional)
Interface
Standard: USB V2.0 HS + Serial
Optional: USB V2.0 HS + Serial + Bluetooth / WLAN
-------------------------------------------------
WLAN: 802.11a/b/g/n (Infrastructure, Ad-hoc,
Wi-Fi Direct, SoftAP)
- WEP40/104, WPA1/2 (PSK, EAP)
-------------------------------------------------
Easy Bluetooth Pairing™ via NFC

Environment Characteristics
Temperature
Sperating: -15 ~ 50℃ (5 ~ 122℉)
Storage: -30 ~ 70℃ (-22 ~ 158℉)
Humidity
Operating: 10 ~ 80% RH
Sealing
IP54
Drop Rate
1.8 m (6 ft.)

Software
Emulation
SLCS, BPL-Z™, BPL-C™
Driver / Utility
Windows Driver (Europlus/Seagull),
Linux/Mac CUPS Driver, Virtual COM USB Driver,
Utility Program, Label Artist-II™, Bartender UL,
OPOS/JPOS Driver, SAP® Device Driver,
Network Auto Installer
SDK / Plugin
Android/iOS/Windows SDK, Linux SDK,
Chrome SDK, Xamarin SDK, Cordova Plugin
Application
Label Artist™ Mobile (Android, iOS),
mPrint App (Android, iOS)

Fonts / Graphics / Symbologies
Fonts
Bitmap Fonts (10 SLCS™, 16 BPL-Z™, 7 BPL-C™),
Scalable Fonts (1 SLCS™, 1 BPL-Z™),
23 Code page,
Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
Graphics
Supporting user-defined fonts, graphics,
formats, layouts and logos
Barcode Symbologies
1D: Codabar, Code 11, Code 39, Code 93,
Code 128, EAN-13, EAN-8, Industrial 2-of-5,
Interleaved 2-of-5, Logmars, MSI, Plessey,
Postnet, GS1 DataBar (RSS-14),
Standard 2-of-5, UPC/EAN extensions,
UPC-A, UPC-E, IMB
2D: Aztec, Codablock, Code 49, Data Matrix,
MaxiCode, MicroPDF417, PDF417, QR code,
TLC 39

Accessories
Standard Accessories
Belt Clip, Battery, Battery Charger, Power Cord
Optional Accessories
Belt Strap, Shoulder Strap, Single Battery Cradle,
Quad Battery Charger, Vehicle Charger,
Serial/USB Cable,
RAM Mount Vehicle Holder, Case

Supplies
Compatible with B-linerless™ BIXOLON’s flexible
and ecological linerless label consumables
