STANDARD FEATURES
• Apple iOS, Android, Windows Mobile and BlackBerry® connectivity
• Direct thermal printing of barcodes, text and graphics
• 203 dpi resolution (8 dots per mm)
• Print speed up to 5"/127 mm per second (with Draft mode enabled)
• CPCL and ZPL® programming languages
• XML support
• Resident fixed and scalable fonts
• 400 MHz 32-bit ARM® processor with 256 MB RAM (8 MB available for user applications)
• 512 MB Flash supports downloadable programs, receipt formats, fonts and
graphics (64 MB available for user storage)
• USB On-The-Go ports (with optional strain relief cable)
• 2450 mAh removable, rechargeable PowerPrecision+ Li-Ion battery
• Built-in battery charger
• Black mark and gap media sensing using fixed center position sensors
• Optional linerless platen
• Cold Temperature Compensation mode-optimizes / balances print speeds
to allow for better print performance at lower temps
• Dual-sided tear bar which allows for clean tear in either direction
(not available with linerless SKUs)
• Supports vertical and horizontal printing
• Printer can be used in any orientation
• Center-loading media locking for variable roll widths
• “Clamshell” design for easy media loading
• Management: Mirror, SNMP, Web server, Profile Manager, AirWatch® and Wavelink Avalanche®
• Bluetooth 4.0 Smart Ready Low Energy radio
• Simple easy-to-read LCD with large icons for battery and wireless status
• Tolerance of multiple drops from 6.6' (2 m) to concrete
• Label odometer
• NTP (Network Time Protocol) support via WiFi
• QR code links to web-based help pages; not displayed on LCD
• Semi-sleep / instant on mode — which allows the printer to “wake” on touch (Wake on BT only supported in BT 4.0 radio), or on Bluetooth print job transmission
• Zebra® Print Touch simplifies Bluetooth pairing and launches web-based help pages with Near Field Communication (NFC) enabled devices
• Power Smart Print Technology — anticipates upcoming printing to optimize battery consumption and print speed

PRINTER SPECIFICATIONS
Resolution 203 dpi resolution (8 dots/mm)

Maximum Print Width

• ZQ510: 2.83"/72mm
• ZQ520: 4.09"/104mm

Maximum Print Speed  Up to 5"/127mm per second

Media Sensors Black mark and gap media sensing using fixed centerposition sensors

Print Length Maximum: 39"

Power 2450 mAh removable, rechargeable PowerPrecision+ Li-Ion battery, with optional extended battery

MEDIA CHARACTERISTICS
Maximum Media Width

• ZQ510: 3.15"/80 mm +1 mm
• ZQ520: 4.45"/113 mm +1 mm

Maximum Media Roll Size

• ZQ510: 2.0"/51 mm
• ZQ520: 2.24"/57 mm
•
  Thickness 0.0063" (0.1600 mm) for labels and 0.0055" (0.1397 mm)
  for tag/receipt
  Media Types Receipt, Gap/Black mark Label, Tag

OPERATING CHARACTERISTICS

Environmental

• Operating Temperature: -4ºF to 131ºF/-20ºC to 55ºC
• Operating Humidity: 10% to 90% non-condensing
• Charging Temperature: 32ºF to 104ºF/0ºC to 40ºC
• Cradle Temperature: 32ºF to 122ºF/0ºC to 50ºC
• Storage Temperature: -22ºF to 150ºF/-30ºC to 66º C
• Storage Humidity: 10% to 90% non-condensing

Agency Approvals

Emissions: FCC Part 15, Subpart B, EN55022 Class-B, EN60950, EN55024 and VCCI class B

Susceptibility: EN55024, EN61000-4-2, EN61000-4-3,
EN61000-4-4, and EN61000-4-5

Safety: CE, UL, TUV, CSA

PHYSICAL CHARACTERISTICS
                  ZQ510             ZQ520
Length      2.4"/62 mm      2.6"/67 mm
Width       4.7"/120 mm    6.1"/155 mm
Height     5.9"/150 mm     6.2"/158 mm
Weight (w/battery) 1.39lbs/0.63 kgs     1.73lbs/0.79 kgs

SOFTWARE TOOLS
Link-OS Solutions
Profile Manager — Advanced, server based device management for
networked printers, operates via a web browser interface
Cloud Connect — Secure, direct, encrypted and authenticated connections
to the web for printing and device management
Virtual Devices — Use legacy and non-Zebra command languages to print
labels and tags
Zebra Utilities — Print from iOS, Android, Windows Mobile devices
Print Station — Driverless printing from Android devices
AirWatch Connector — Manage from within the AirWatch environment
Multiplatform Software Development Kit — Simplifies printing application development with support for Blackberry, Apple, Android, WinCE®, WinMobile®,Windows desktop and Linux/Unix platforms

BARCODE SYMBOLOGIES

CPCL Barcode Symbologies
• Barcode Ratios: 1.5:1, 2:1, 2.5:1, 3:1, 3.5:1
• Linear Barcodes: Code 39, Code 93, UCC/EAN128, Code 128, Codabar (NW-7),Interleaved 2-of-5, UPC-A, UPC-E, 2 and 5 digit add-on, EAN-8, EAN-13, 2 and5 digit add-on
• 2D Barcodes: PDF417, MicroPDF417, MaxiCode, QR Code, GS1/DataBar™ (RSS)
family, Aztec, MSI/Plessey, FIM Postnet, Data Matrix, TLC39
ZPL Barcode Symbologies
• Barcode Ratios: 2:1, 3:1, 5:2, 7:3
• Linear Barcodes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A,UPC-E, EAN-8, EAN-13, UPC-A and UPC-E with EAN 2 or 5 digit extensions,Planet Code, Plessey, POSTNET, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Codabar, and GS1 DataBar (RSS)
• 2D Barcodes: PDF417, MicroPDF-417, Code 49, TLC39, Maxicode, Codablock, Data Matrix, QR code, Aztec
