PHYSICAL

Dimensions (L x W x H): 297 mm x 226 mm x

177 mm (11.7 in x 8.9 in x 7.0 in)

Weight: 2.5 kg (5.5 lbs)

MEDIA

Processor: 2.26 GHz Qualcomm Snapdragon 801

Max. Media Diameter: 127.0 mm (5.0 in)

Media Core Sizes: 25.4 mm (1.0 in), 38.1 mm (1.5 in)

Media Width: 25.4 mm (1.0 in) to 110 mm (4.3 in)

Min. Label Length: 9.6 mm (0.3 in)

RIBBON

Ribbon Support: Coated Side Out

Max. Ribbon Diameter: 68.0 mm (2.7 in)

Ribbon Core Sizes: 12.7 mm (0.5 in), 25.4 mm (1.0 in)

Ribbon Width: 25.4 mm (1.0 in) to 109.2 mm (4.3 in)

Max. Ribbon Length: 25.4 mm (1.0 in) core: 300.0 m (984.0 ft); 12.7 mm (0.5 in) core: 75.0 m

(246.0 ft)

PRINTING

Print Resolution: 8.0 dpmm (203 dpi)

Max. Print Speed: 101.6 mm/s (4.0 ips)

Max. Print Width: 104.1 mm (4.1 in)

COMMUNICATIONS

Standard Interfaces: USB Device, USB Host

Options: Factory-Installed: Internal Ethernet, serial port

Protocols: Network: TCP/IP-suite (TCP, UDP, ICMP, IGMP), DHCP, BOOTP, LPR, FTP, web page and

Telnet 9100, IPv4 Serial Flow Control: XON/XOFF, RTS/CTS

USER INTERFACE

Display: 1 Feed Button and LED Display

Web Page Languages: English and Simplified Chinese (Default), Spanish, Portuguese, Russian,

Korean, Japanese, Thai

GRAPHICS AND BARCODES

Native Graphic Formats: 1-bit BMP, GIF, PCX, PNG

Barcode Symbologies: All major 1D and 2D symbologies are supported, including Aztec, Code

16K, Code 49, Data Matrix, Dot Code, EAN-8, EAN-13, EAN, UCC 128, Grid Matrix, HIBC 39, HIBC

128, MaxiCode, MSI (modified Plessey), PDF417, Micro PDF417, Planet, Plessey, Postnet, QR-Code,

RSS-14 (variations)

SOFTWARE

Printer Command Languages: Direct Protocol

(DP), ZSim (ZPL II), ESim (EPL)

Drivers: BarTender™, InterDriver Windows™

Printer Driver

Character Sets: English & Extended Latin, Arabic,

Baltic & Baltic Rim, Cyrillic, Greek, Hebrew, Thai,

Turkish, Vietnamese and more with Monotypeฎ

Universal Font Scaling Technology (UFST) and

WorldType Layout Engine (WTLE)

ENVIRONMENTAL

Operating Temperature: +5°C to +40°C (+41°F to +104°F) @ 10 to 80% RH non-condensing

Storage Temperature: -40°C to +60°C

(-40°F to +140°F) @ 10 to 90% RH

ELECTRICAL

Input: 100–240V AC @ 50–60 Hz, 1.5 A

Output: 24V DC, 2.5 A

MEMORY

Standard: 64 MB Flash, 64 MB SDRAM

Optional: Up to 32 GB (via user-supplied USB thumb drive) formatted as FAT16 or FAT32

OPTIONS

Factory-Installable: Ethernet, serial port

APPROVALS

Regulatory: UL, cUL, cULus, CE, FCC Class A, D

Mark CCC, KCC, RCM

Safety:

North America: UL & cUL Listed, UL 60950-1

Europe: D Mark, EN 60950-1; CE

Mexico: NYCE Certified, NOM 19

Other Countries: IEC 60950-1

EMC: USA FCC Title 47, Part 15, Subpart A,

Class A; Europe EMC Directive (EN55022 Class A +

EN55024); CISPR22
