SMART-31S Specifications

Printing
Print Mode : Single Sided
Print Type  :  Direct Dye-Sublimation
Print Area  :  Edge to Edge
Resolution  :  300 dpiDual
Sided Printing  :  Option (with Flipper)

Card
Card Feeding  :  Automatic
Card Size  :  ISO CR80
Card Thickness  :  0.38mm (15mil), 0.76mm (30mil)
Card Type  :  PVC, PET, Composite PVC

Print Speed
Monochrome  :  5 sec/card (720 cards/hour)
YMCKO  :  Max. 23 sec/card (156 cards/hour)

Capacity
Input Card Hopper   :  80 Cards
Output Card Hopper  :  25 Cards

System
Memory  :  64MB RAM
Interface  :  1 LED Buttons
Supported Platforms  :  Microsoft Windows 7/8/10, Mac OS, Linux
Communication  :  USB, Ethernet (Option)
Power Supply   :  Free Voltage (AC100/220V, 50~60Hz)
Power Consumption  :  48WTemperature  :  15~35℃Humidity  :  35~70%

Dimensions
Milimeter  :  172 (W) x 377 (L) x 190 (H)
Inch  :  6.8 (W) x 14.8 (L) x 7.5 (H)
WeightKg / Lbs   :  3.4 / 7.5

Encoding
OptionMagnetic  :  ISO 7811 (Track I, II, III Read/Write, HiCo/LoCo), JIS II
Contact  :  ISO 7816 A/B/C Card, ISO 7816 1/2/3/4 Microprocessor Card
Contactless  :  ISO 14443 (Type A/B), MIFARE, DESFIRE, iCLASS, ISO 18092(NFC), Felica

Certifications
Certifications  :  CB, CE, FCC, KC, CCC
