PHYSICAL CHARACTERISTICS

Dimensions
Corded:
7:3 In. H x 3.0 In. Wx 5.2 In. D
18.5 cm H x 7.6 cm Wx 13.2 cm D
Cordless:
7:3 In. H x 3.0 In. Wx 5.6 In. D
18.5 cm H x 7.6 cm Wx 14.2 cm D
Weight
Corded: 10.76 oz./305 g
Cordless: 14.34 oz .1407 g
Input Voltage Range
Host powered: 4.5 VDIC min., 5.5 VDIC max.
External power supply: 11.4 VDC mln., 12.6 VDC max.
Operating Current : DS 3608-SR (co rded): 360 mA (RMS typical)
Standby Current : DS 3608-SR (corded): 100 mA (RMS typical)
Color : Industrial Green
Supported Host Interfaces :
USB, RS 232, Keybo ard Wedge Industrial Ethernet: EtherNet / P, Profinet, Modbus TCP & Std TCPAAP
Battery : PowerPrecislon+ 3100 mAh Li-lon rechargeable battery
User Indicators : Direct decode Ind Ic ator, LEDs; beeper, vibration

PERFORMANCE CHAR ACTERISTICS
Scans per Full Charge : 100,000+
Image Capture : Basic
Illumination : One (1)660 nm LED
Aimer : 610 nm LED
Imager Field of View : Hortzontal: 42', Vertical: 28"
Image Sensor : 1,280 x 800 plxels
Minimum Print Contrast : 15% minimum reflective difference
Skew/Pitch/Roll : Skew: +60%, Pitch: +60', Roll: : 360"

DECODE CAPABILITIES**
1D :Code 39, Code 128, Code 93, Coda bar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Ital lan Pharma)
2D : PDF417, Micro PDF 417, Compos ite Codes, TLC-39,Aztec, Data Matrix, MaxICode, OR Code, MIcro OR, Chinese Sensi ble (Han Xin), Postal Codes, DotCode
Digimarc : Digltal watermark technology
IUID Support :
Supports I UID parsing, the abilty to read and
separate I UID flelds per application requlrements

USER ENVIRONMENT
Operating Temp. :
Corded: -22°F to 122° F1-30°C to 50°C
Cordless: -4°F to 122°F-20°C to 50°C
Storage Temp. : -40°F to 158°F-40°C to 70°C-40°F to 158°F-40°C to 70°C
Humidity : 5% to 95% non-condensing
Drop Specification : Withstands multiple 8.0 ft./2.4 m drops to concrete

USER ENVIRONMENT (CONTINUED)
Tumble Specification : 5,000 tumbles @ 3.3 ft. (1m)
Sealing : Scanner. IP65 and IP67
FLB cradle: IP65
ESD : Per EN 61000-4-2, +25 KV alr discharge, t10 KV direct discharge, 10 KV Indlrect discharge

WIRELESS CONNECTIVITY
Bluetooth Radio : Bluetooth Class 1, Verslon 4.0 (LE), serlal port and HID profles
Data Rate
3 Mbit/s ( 2:1 Mbit/s) for Classic Bluetooth
1 Mblt/s (0.27Mblt/s) for Low Energy
Radio RangeDirect IIne of sight In open alr. Class 1: Minlmum 300 ft. (100.0 m); Class 2: MInImum 30 ft. (10.0 m)

DECODE RANGES
Symbology/Resolution Near/Far
Code 128:5 mil : 1.3-6.7in./3.3-17 cm
Code 128: 20 mil : 2.8-28.0 in./7.1-71.1 cm
Code 128: 40 mil : 1.7-60 in./4.4152.4 cm
Datamatrix: 7.5 mil : 1.9-6.0 in./ 4.8-15.2 cm
Datamatrix: 10.0 mil : 1.4-8.6 in./3.5-21.8 cm

REGULATORY
Environmental :ROHSEN 50581: 2012
Electrical Safety
EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011+ AC 2011 + A2: 2013
International Safety: IEC 60950-1: 2005 + A1:2009 + A2: 2013
US/Canada Safety: UL 60950 -1, second edition,CAN/CSA-C22.2 No.60950-1-07
LED Safety
Internatlonal LED Safety: EC 62471: 2006 (Ed.1.0); EN 62471: 2008(LED)

EMI/RFI
IT Emisslons: EN 55022: 2010/AC: 2011 (Class B)
IT Immunity: EN 550 24: 2010
Heavy Industrial: EN 61000-6-2: 2005/AC:2005
Harmonic Current E misslons: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B)
Voltage Fluctuation and Flicker: EN 61000-3-3: 2013
Medical Electrical Equlpment: EN 60601-1-2:2007/AC: 2010, IEC 60601-1-2: 2007 (Modlfled)
Radlo Frequency Devices: 47 CFR Part 15, Subpart B. Class B
Digital Apparatus: I CES-003 Issue 5, Class B
